Proton Exchange Membrane Fuel Cell(PEMFC) Lumped Modeling and Dynamic Performance Analysis

Abstract:

A model of PEMFC is developed that captures dynamic behavior for control purposes. It analyzes in detail the influence factor of voltage of PEMFC. The model is mathematically simple, and accounts for the essential phenomena that influence the PEMFC performance. The partial pressure of hydrogen and oxygen can be found using the laplace transform and differential form of ideal gas state equation. It is assumed that the mixture ratio of hydrogen and oxygen in the reaction are constant, the dynamic lumped model of PEMFC is proposed. The model is verified by comparing the experiment data with simulation result of model. On the basis of the dynamic model, the partial pressure and voltage are analyzed when when the load current suddenly changes.The research about lumped model has important significance to the research of the distributed generation network in various performances and has guiding meaning to the structure design of fuel cell.

• Periodical: Advanced Materials Research (Volumes 197-198)
• Pages: 719-723
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.197-198.719
• Online since: February 2011
• Authors: Qiu Hong Jia, Ming Han, Bin Deng, Cai Zhi Zhang, Yan Xiao
• Keywords: Dynamic Response Characteristic, Gas Partial Pressure, PEMFC Lumped Model

References

[1] Mann R F , Amphlettj C: J. Power Sources. Vol. 86 (2000) , pp.73-80.

[2] Khan M J , Iqbl M T: Fuel Cells. Vol. 5 (2005) , pp.463-475.

[3] Han Ming: Nanyang Technological university, Doctor of Philosophy, (2007).

[4] Hernadez A, Hisel D: Fuel Cells. Vol. 1 (2006) , pp.38-46.

[5] James Larminie and Andrew Dicks: Fuel Cell System Explained. 2nd ed. John Wiley &Sons Ltd., (2003), pp.1-4.

[6] Larminie J, Dicks A. Fuel cell system explained. 2nd ed. John Wiley & Sons Publication, (2003).

[7] Kim J., Lee S., Srinivasan S., Chamberlin C.E. J. the Electrochemical Society. Vol. 142(1995), pp.2670-2674.

[8] Correêa JM, Farret FA, Canha LN, Simo ˜ es MG: IEEE Transactions on Industrial Electronics Vol. 5(2004), p.1103–1112.

[9] Yerramalla Sampath, Davari Asad, Feliachi Ali: J. Power Sources. Vol. 24(2003), pp.104-113.
