Dynamic Analysis of the Pipe Lifting Mechanism on the Deepwater Pipelaying Vessel

Abstract:

Based on requirements of pipe transport systems on deepwater pipelaying vessel, a new pipe lifting mechanism was designed. It was composed of crank-rocker and rocker-slider mechanism with good lifting capacity and high efficiency. When the slider went to the upper limit position, the mechanism could approximatively dwell, meeting the requirement for transverse conveyor operation. According to the theory of dynamics, numerical analysis method was used to the dynamic analysis of the mechanism. The results showed the maximum counterforce was at the joint between the rocker and ground, and this calculation could be a guideline for the kinematic pair structure designing.

• Periodical: Advanced Materials Research (Volumes 199-200)
• Pages: 251-256
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.199-200.251
• Online since: February 2011
• Authors: Kai An Yu, Ke Yu Chen
• Keywords: Dynamic Analysis, Numerical Method, Pipe Lifting Mechanism

References

[1] Haijun Gu: J. Journal of ship design. Vol. 121 (2009), p.13.

[2] Yun Pan, Feng Cheng, Ruijian Jin and Jinlong Qi: J. Ship & Boat. Vol. 3 (2010), p.49.

[3] Hong Zhang.: J. petroleum machinery. Vol. 36 (2008), p.201.

[4] Yun Pan: J. Ship & Boat. Vol. 4 (2009), p.8.

[5] Fuming zhang: J. Shanghai shipbuilding. Vol. 2 (2010), p.56.

[6] Yongsheng Shen: Principle of Mechanic. (Tsinghua University press, China 2005).

[7] Yiyong Yang, Dewen Jin: Dynamics. (Tsinghua University press, China 2009).

[8] Ce Zhang: Dynamics. (Academic press, China 2000).
