Study and Design of CAN Bus Node Based on MC912D60A Microcontroller in Automobile

Abstract:

Controller Area Network (CAN) is a kind of serial communication network that supports the distributed control and the real time control. The CAN have high performances and high reliabilities. It can solve many problems of complex circuitry, wiring harness increasing, operation reliability reducing and the difficulty of fault maintain increasing while using CAN Bus technology in automobile. In this paper, the form of CAN bus and node design method based on MC912D60A single chip microcomputer were studied and introduced. At last, the hardware design principle diagrams and software flow charts were given.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 2317-2321
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.2317
• Online since: February 2011
• Authors: Ji Fei Chen, Long Qing Zhao
• Keywords: CAN Bus, MC912D60A Single Chip Microcomputer, Node Design
