Lightweight Design of Electric Scooter Frame by Finite Element Optimization

Abstract:

To reduce the weight of the electric scooter frame, magnesium alloy is used to replace the steel. At the same time, the frame structure and tube thickness are redesigned by using topology optimization and size optimization respectively. In addition, static analysis and mode analysis of the frame are carried out to realize the application capability and dynamic capability. Compared with the original steel frame, mass of the magnesium alloy frame after optimization has been reduced by 60%, and the natural frequency has been improved greatly. The results show that the strength and the rigidity of the new structure can meet the designed demand.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 49-53
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.49
• Online since: February 2011
• Authors: Hong Bo Dong, Wei Zhang
• Keywords: Electric Scooter Frame, Finite Element Analysis (FEA), Structure Optimization

References

[1] Yunkai GAO, Dekan MENG and Xi JIANG: China Mechanical Engineering, Vol. 17(2006), p.2522 (In Chinese).

[2] F. Navarrina, I. Muinos, I. Colominas and M. Casteleiro: Advances in Engineering Software, Vol. 36(2005), p.599.

[3] S.L. Lee, D.C. Lee, J.I. Lee, C.S. Han and K. Hedrick: Finite Elements in Analysis and Design, Vol. 43(2007), p.620.

[4] B. Torstenfelt and A. Klarbring: Finite Elements in Analysis and Design, Vol. 43(2007), p.1050.

[5] Qichi LE, Xinjian ZHANG and Jianzhong CUI: Materials Review, Vol. 16(2002), p.12 (In Chinese).

[6] A. Tharumarajah and P. Koltun: Journal of Cleaner Production, Vol. 15(2007), p.1007.

[7] Shu WANG, Chunsheng SHI, Naiqin ZHAO and Zhongxia XIANG: Materials Review, Vol. 20(2006), p.87 (In Chinese).

[8] Yuanfang FU, Dafeng JIN and Weiwei QIAO: Journal of Mechanical Engineering, Vol. 45(2009), p.210 (In Chinese).

[9] Weihong ZHANG, Jungang YANG and Jihong ZHU: Acta Aeronautica Et Astronautica Sinica, Vol. 30(2009), p.2335 (In Chinese).
