The Analysis of the Temperature Field and Deformation of Cylinder Liner Base on Finite Element Method and Experiment

Abstract:

The distortion of the cylinder liners of internal combustion engines has a significant affect on engine operation. It can affect the oil consumption, the blow-by, the wear behavior and, due to friction, the fuel consumption. In order to achieve future requirements regarding exhaust emissions and fuel consumption, the development of low distortion engine blocks will play a significant role. Finite element method with experimental data were used to calculate and analysis the temperature field and machine assembly of a 150 engine cylinder liner in this paper. It can provide a theoretical basis for the controlling of the cylinder liner deformation.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 30-35
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.30
• Online since: February 2011
• Authors: Kun Li, Tie Xiong Su, Xiao Jie Li, Shi Xin Xing
• Keywords: Cylinder Liner, Deformation, Experiment, Finite Element Model (FEM), Temperature Field

References

[1] Grogeneweg M.A. Current Application of Finite Element Analysis to Diesel Engine Component Design [J]. SAE Paper 870813.

[2] Gilson A. Vicentini, Jan Vatavuk. Study of Sea Transportation Effects on Corrosion of Cast Iron Cylinder Liners [J]. SAE Paper 2001-01-3978.

DOI: 10.4271/2001-01-3978

[3] Pranz Koch, Poul Decker. Cylinder Liner Deformation Analysis-measurements And Calculation [J] . SAE Paper 980567.

[4] J. Abraham, D. R Amoth,J. Mannisto. 3D Steady-State Wall Heat Fluxes and Thermal Analysis of a Stratified-Charge Rotary Engine [J]. SAE Paper 910706.

DOI: 10.4271/910706

[5] Yang Shiwen , Zhang Yi , Su Tiexiong , et al. Distortion analysis and structural parameters optimization of cylinder liner of heavy duty diesel engines[J] . Chinese Internal Combustion Engine Engineering, 2003, 24 (2) : 252 29. (in Chinese).
