Design and Application of Flexible Auxiliary Haulage System for Material Supply in Underground Coal Mine

Abstract:

In view of the problems existing in the present transportation ways of coal mine, a kind of new auxiliary haulage system has been designed, which can achieve the going there and back transportation only by using one winch in the multi-slope and undulating roadway. And according to the requirements of safety production of coal mine, the non-wheeled supply mine car without anti-car device and the safety interlock system of wheeled supply mine car have been designed. Meanwhile, finite element analysis software is adopted to check and analyze the locking pawl strength of the safety interlock system with wheeled supply mine car. The analyzing result shows that the locking pawl can completely stand the impact loading when the mine car sliding down. The haulage costs and the occurrence of security incidents have been reduced when the designed system is applied to coal mine. Engineering practice shows that the good results have been achieved.

• Periodical: Advanced Materials Research (Volumes 201-203)
• Pages: 524-528
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.201-203.524
• Online since: February 2011
• Authors: Ju Cai Chang, Qing Hua Chen
• Keywords: Auxiliary Haulage, Design, Flexible System, Underground Coal Mine

References

[1] Xueqian YU: Transportation Machine of Coal Mine (China University of Mining and Technology Press, Xuzhou, 2009) (In Chinese).

[2] WEI Wen-hui, XING Tian-hai and LIU Qiang: Application of Electric Monorail Crane to Gateway of Coal Mining Face, Coal Science and Technology, Vol. 37 (2009), pp.83-85 (In Chinese).

[3] JIN Xiang-yan: Reconstruction design on mine auxiliary transportation system in Wangpo Mine, Coal Egineering, Vol. 3 (2008), pp.7-9 (In Chinese).

[4] ZHANG Xiuliang: Narrow Roadway Were Expected to Fly Ropeway Transport Personnel and Material Technology Research, Coal Mine Machinery, Vol. 31 (2010), pp.177-179 (In Chinese).
