The Research of Large-Diameter & Energy-Saving More Medium Supplied Gravity-Fed Three-Product Heavy Medium Cyclone

Abstract:

The characteristics and the development restrict factors in large-diameter area of the traditional three-product heavy medium cyclone are described. The paper mainly describes the structure and principles of large-diameter & energy-saving more medium supplied gravity-fed three-product heavy medium cyclone. The simulation analysis of this cyclone (DWP type) is presented. The results show that this type of more medium supplied cyclone is better than the one medium supplied cyclone for it has a faster separation speed, high processing ability and better separation efficiency. The applications in field of the 3SNWX1500/1100-Ⅳ type cyclone which using the new technology indicated that there have energy-saving, a high output, a stable separation efficiency, a high precision and a significant economic benefits.

• Periodical: Advanced Materials Research (Volumes 211-212)
• Pages: 1072-1076
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.211-212.1072
• Online since: February 2011
• Authors: Ping Huo, Li Qiang Zhang, Jing Bo Jia
• Keywords: Cyclone, Gravity-Fed, Heavy Medium, Large-Diameter, More Medium Supplies

References

[1] Rurui Wang: Theory and Practice of H.M. coal separation(China Coal Industry Press, Beijing 1988), in Chinese.

[2] Liqiang Zhang, Qin Yun and Guo Xiujun: Journal of Coal Preparation Technology Vol. 4 (2007), pp.137-140, in Chinese.

[3] Feng Liu, Honggang Le: More medium supplies non-pressure feeding heavy medium three products cyclone. Chinese patents：ZL200620023458. X，4. 4. 2007, in Chinese.

[4] Liqiang Zhang, Yun Qin and Xiujun Guo: Journal of Coal Preparation Technology Vol. 4 (2009), pp.1-5, in Chinese.

[5] Feng Liu, Aijun Qian: Journal of Coal Preparation Technology Vol. 5 (2004), pp.10-14, in Chinese.
