The Influence of Preheating on Automated Fiber Placement Speed

Abstract:

The influence of preheating adopted and preheating unadopted on manufacturing speed during the automated fiber placement process has been analyzed. According to Fourier heat equation and assuming the towpreg with uniform material properties, a heat transfer model of towpreg has been established. The boundary conditions and initial conditions of this model at different stages have been given based on energy exchange principle. The research chooses thermoplastic composite APC-2(carbon/PEEK) as the towpreg material and utilizes the finite element method to investigate the temperature history of the fiber placement process. Since fiber placement speed is related with the response time of temperature, it can be obtained by the temperature history. Finally, the results demonstrate preheating can significantly improve the fiber placement speed.

• Periodical: Advanced Materials Research (Volume 213)
• Pages: 136-142
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.213.136
• Online since: February 2011
• Authors: Yue Hua Li, Hong Ya Fu, Zhong Xi Shao
• Keywords: Fiber Placement Speed, Heat Transfer Modeling, Preheating, Response Time

References

[1] Munki Lee, Heat Transfer and Consolidation Modeling of Composite Fiber Tow in Fiber Placement, Ph.D. dissertation, Department of Mechanical Engineering, Virginia Polytechnic Institute and State University, (2004).

[2] S. M. Grove, Thermal Modelling of Tape Laying with Continuous Carbon Fibre-Reinforced Thermoplastic, Composites, Vol. 19, Sep. 1988, pp.367-375.

DOI: 10.1016/0010-4361(88)90124-3

[3] Fazil O. Sonmez, and H. Thomas Hahn, Modeling of Heat Transfer and Crystallization in Thermoplastic Composite Tape Placement Process, Journal of Thermoplastic Materials, Vol. 10, 1997, pp.198-240, doi: 10. 1177/08927079701000301.

DOI: 10.1177/089270579701000301

[4] X. Guan, and R. Pitchumani, Modeling of Spherulitic Crystallization in Thermoplastic Tow-Placement Process: Heat Transfer Analysis, Composite Sicence and Technology, Vol. 64, 2004, pp: 1123-1134.

DOI: 10.1016/j.compscitech.2003.08.011

[5] M. A. Lamontia, M. B. Gruber, J. J. Tierney, J. W. Gillespie, Jr., B. J. Jensen, and R. J. Cano, Modeling the Accudyne Thermoplastic In Situ ATP Process, 30th International SAMPE Europe Conference, Mar. 2009, pp: 23-25.

[6] Mehrdad N. Ghasemi Nejhad, Thermal Analysis for Thermoplastic Composite Tow/Tape Preheating and Pultrusion, Journal of Thermoplastic Composite Materials, Vol. 10, Nov 1997, pp: 504-523.

DOI: 10.1177/089270579701000601

[7] Po-Jen Shih, On-Line Consolidation of Thermoplastic Composites, Ph. D dissertation, Department of Mechanical Engineering, Virginia Polytechnic Institute and State University, (1997).
