Analysis on the Contact Pressure Distribution of Chemical Mechanical Polishing by the Bionic Polishing Pad with Phyllotactic Pattern

Abstract:

In order to make the contact pressure distribution of polishing wafer surface more uniform during chemical mechanical polishing (CMP), a kind of the bionic polishing pad with sunflower seed pattern has been designed based on phyllotaxis theory, and the contact model and boundary condition of CMP have been established. Using finite element analysis, the contact pressure distributions between the polishing pad and wafer have been obtained when polishing silicon wafer and the effects of the phyllotactic parameter of polishing pad on the contact pressure distribution are found. The results show that the uniformity of the contact pressure distribution can be improved and the singularity of the contact pressure in the boundary edge of polished wafer can be decreased when the reasonable phyllotactic parameters are selected.

• Periodical: Advanced Materials Research (Volume 215)
• Pages: 217-222
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.215.217
• Online since: March 2011
• Authors: Y.S. Lv, Nan Li, Jun Wang, Tian Zhang, Min Duan, Xue Ling Xing
• Keywords: Bionic Polishing Pad, Chemical Mechanical Polishing (CMP), Contact Pressure Distribution, Phyllotaxis, Silicon Wafer

References

[1] J.X. Su, R.K. Kang, D.M. Guo, etal: Lubrication Engineering, Vol. 3(2005), pp.1-4.

[2] Y.S. Lv, L.Y. Zhang, J. Wang, etal: Acta ArmamentarⅡ, Vol. 4(2008), pp.495-499.

[3] Daved. A. Dornfeld: University of California(at Berkeley), (2005).

[4] Y.Y. Lin, S.P. Lo: The International Journal of Advanced Manufacturing Technology, Vol. 23(2004), pp.644-650.

[5] J. J. Vlassak: Journal of the Mechanics and Physics of Solids, Vol. 52(2004), pp.847-873.

[6] R.V. Jean: Mathematical Biosciences, Vol. 64(1983), pp.1-27.

[7] H. S. M. Coxeter: Introduction to geometry (New York), (1961).

[8] D. A. Young: Journal of Theoretical Biology, Vol. 71(1978), p.421–423.

[9] H. Vogel: Math Biosci, Vol. 44(1979), pp.179-189.

[10] Saeed. Moaveni: Publishing House of Electronics Industry, (2008).
