Microscopic Mechanism Analysis and Experimental Study of Void Beneath Slab

Abstract:

The main cause of cement concrete pavement fracture is void beneath slab, while water is an important factor of void beneath slab. In order to clearly understand impact of water on void beneath cement concrete pavement, this paper analyzes penetration soaking role and scouring of water and studies the evolution process of void under slab. It is founded that the erosion of the grassroots and void beneath the plate influence each other. Conducting a Small-size simulation test by using Falling Weight Deflectometer (FWD), the movement condition of the water in empty area under concrete road and the effect of void size on current scour are got under the action of moving load.

• Periodical: Advanced Materials Research (Volumes 225-226)
• Pages: 692-696
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.225-226.692
• Online since: April 2011
• Authors: Hai Ying He
• Keywords: Evolution Process, Simulation Test, Void Beneath Slab, Washout Function

References

[1] Jiang Xiwei, Huang Gang. Mechanism of the void beneath cement-concrete slab [J]. Anhui Architecture, 2009, (3): 75-77.

[2] Himeno K, Kamijima T, Ikeda T, et al. Distribution of tire contract pressure of vehicles and its influence on pavement distress [M]/ Proceedings of 8th International Conference on Asphalt Pavements. Washington: the International Society for Asphalt Pavements, 1997: 129-139.

[3] Qun Lizhang, Wang Duanyi. Voids under the Concrete Slabs and the Detective Methods[J]. Central South Highway Engineering, 2007, 32(3): 106-108.

[4] Darter M I, Becker J M, Snyder M B, et al. Portland cement concrete system pavement evaluation system(COPES)[R]. Washington D.C.: Transportation Research Board, (1985).

[5] Chen Jinzhong. Characteristics of Roadbed Strength and Deformation under Water Capillary[J]. Journal of Shanxi Datong University(Natural Science), 2008, 24(3)：53-55.

[6] Zhan Minghua, Liu Xiao-ping, Chen An. Analysis of Capillary Effect in Unsaturated Roadbed[J]. Journal of Highway and Transportation Research and Development, 2008, 25(8)：26-30.

[7] Sha Aimin. Material Characteristics of Semi-rigid Base[J]. China Journal of Highway and Transport, 2008, 21(1)：1-5.

[8] Tan Zhiming, Tan Fuping. Analytical model pertaining water flow in void domain under the cement concrete pavement slabs[J]. Chinese Journal of Hydrodynamics, 2008, 23(3)：281-286.

[9] Liang Yunlin. Study on Fracture Mechanics and use of Portland Cement Concrete Pavement[D]. Chang'an University, (2004).

[10] Zhang Tiefu, Yang Qingguo, Yi Zhijian, Zhao Chaohua, Gu Jianyi. Fracture Mechanism and Simulation of Cracks on the Bottom of Concrete Slab under Water Pressure Effect[J]. Journal of Chongqing Jiaotong University (Natural Science), 2007, 26(5): 61-63.
