Research on the Impeller Tip Screenout Fault Feature Extraction of the Submersible Pump Units Based on Wavelet Analysis

Abstract:

The sealed electric submersible pumps (ESP) are the main device to extract oil in the world. Many faults of ESPs can lead to fierce vibration. The impeller tip screenout fault may shorten the service life of ESP, even lead to halt. The vibration signals were acquired from normal ESPs and impeller tip screenout fault ESPs, with vibration acquisition instrument based on three-dimensional piezoelectric sensor. The typical frequency characteristics were extracted from the well-head vibration data of normal and fault ESPs with wavelet analysis. According to the fault feature, the key characteristics of impeller tip screenout fault were extracted, with which the malfunction ESPs on spot can be distinguished from normal ones. The test result indicates that the method can be used in oil field to diagnose impeller tip screenout fault efficiently.

• Periodical: Advanced Materials Research (Volumes 225-226)
• Pages: 835-838
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.225-226.835
• Online since: April 2011
• Authors: Guang Fu Liu, Feng Yang Tao, Xin Guang Li
• Keywords: Electric Submersible Pump (ESP), Fault Diagnosis, Impeller Tip Screenout, Vibration Signal, Wavelet Analysis

References

[1] XI Wen-jing. Research on Fault Diagnosis of Electric Submersible Pumps Based on Vibration Detection [Master Thesis]. Dongying: China University of Petroleum (East China), 2008, 5.

[1] Trevisan, Francisco Exaltacao, Ph.D. Modeling and visualization of air and viscous liquid in Electrical Submersible Pump[J]. 2009, 11: 42-48.

[3] Behzad M., Bastami A, R., Maassoumian M. Fault Diagnosis of Centrifugal Pump by Vibration Analysis[C]. Proceedings of 7th Biennial Conference on Engineering System Design an analysis. 2004, 3: 221-226.

DOI: 10.1115/esda2004-58534

[4] Li Xinlian. Time-frequency Analysis of Mechanical Vibrating Signal [J]. Journal of Shandong Institute of Engineering, 1999, 3.

[5] Pang Peilin, Ding Guangbin. Vibration diagnosis method based on wavelet analysis and neural network for turbine-generator[C]. Control and Decision Conference. 2009: 5234-5237.

DOI: 10.1109/ccdc.2009.5195038

[6] Chen Xiang-jun, Gao Zhan-feng, Ma Yue-e, Guo Qiang. Application of Wavelet Analysis in Vibration Signal Processing of Bridge Structure[C]. 2010 International Conference on Measuring Technology and Mechatronics Automation (ICMTMA). 2010, 1: 671 – 674.

DOI: 10.1109/icmtma.2010.95

[7] LI Xin-guang. Research on the Fault Diagnosis of the Submersible Pump Units Based on Analysis of Vibration Signals [Master Thesis]. Dongying: China University of Petroleum (East China), 2010, 5.
