VV Modulation System of Circulating Pump Based on Fuzzy Control

Abstract:

In order to improve the low thermal efficiency of Solar Energy Fission Geyser, a VV modulation control system of circulating pump based on fuzzy control has been designed. In this system, SCM P89LPC930 is the core. A digital temperature sensor of 1-wire bus LTM8871 is used to detect the real-time temperature and an inner comparator of P89LPC930 to detect the zero point. According to fuzzy control rules, a best angle is chosen. This technology is applied to drive the AC motor to get constant temperature differential. The system is effective in improving the thermal efficiency and poor circulation by avoiding frequent start-up of circulation pump. The innovation points lie in the system uses a minimum hardware circuit design and fuzzy control, with easy circuit, reliable performance characteristics, thus having a high application value.

• Periodical: Advanced Materials Research (Volumes 225-226)
• Pages: 890-894
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.225-226.890
• Online since: April 2011
• Authors: Xian Juan Wang, Jun Er Ma, Dong Bi Zhu
• Keywords: Energy Fission Geyser, Fuzzy Control, SCM, Temperature Differential Solar, VV Modulation

References

[1] Wang Xianjuan, in: Measuring and controlling system of fission solar water heaters based on single chip ,edited by Microcomputer Information 2007,6 (2) : 1131-112.

[2] Tang Bingyong, Lu Linji, soup WangWenjie, in: Fuzzy Control Theory And Application Technology edited by. Beijing: Tsinghua University Press, 2002.

[3] Zhou Ligong: volume 1 of Flash Microcomputer Application Technology of LPC900 Series (Beijing Aerospace University Press2004)

[4] Li hua: Microcontroller Practical Interface Technology of MCS-51Series (Beijing Aerospace University Press, Beijing 1993) 2007 Annual Research Fund Project Funding of Zhejiang Provincial Water Resources Bureau (RC0705)
