Improvement of Stamping Forming Process and Design of Fully Automatic Die for Lipstick Casing Pipe

Abstract:

According to its structure and dimension, the original stamping forming process of the lipstick casing pipe was analyzed. In view of such drawbacks as dispersed working procedures, lower efficiency and unstable product quality in the original manufacturing process, wall thickness of the lipstick casing pipe was modified and became thinner than its original size with the premise of ensuring utility performance. A new manufacturing process for the modified lipstick casing pipe was provided and a fully automatic stamping die, which is more secure in operation, lowers raw material expense and has higher production efficiency, was designed.

• Periodical: Advanced Materials Research (Volumes 230-232)
• Pages: 448-452
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.230-232.448
• Online since: May 2011
• Authors: Chao Ge Zhang
• Keywords: Fully Automatic Stamping Die, Ironing, Lipstick Casing Pipe, Stamping Process Improvement

References

[1] Xiaopei Wang: Stamping Manual (China Machine Press, Beijing 2000), in Chinese.

[2] Ruhua Zhang, Xiangyang Zhao, Yuerong Zhang: Stamping Process and Mold Design (Tsinghua University Press, Beijing 2006), in Chinese.

[3] Suping Wang: Stamping Die Design Structure Figure Collection (Chemical Industry Press, Beijing 2005), in Chinese.
