Study on Macro/Micro Complex Feed Mechanism in Dry-ECD Assisted Truing and Dressing of Diamond Wheel

Abstract:

A novel truing and dressing method, namely dry electrical discharge (dry-ECD) assisted truing and dressing, is proposed to overcome the shortcomings associated with conventional mechanical dressing methods, ELID and ECD methods. The macro/micro complex feed mechanism in dry –ECD assisted truing and dressing equipment is designed to maintain continuous discharge between the tool electrode and diamond wheel in dry-ECD automatically. A series of basic performance experiments of the micro feed mechanism show that the position accuracy of the micro-feed mechanism is below 0.35μm using the micro-positioning control system. Whereas，the position accuracy of the mobile negative electrode is 1μm without macro/micro complex feed mechanism.

• Periodical: Advanced Materials Research (Volumes 24-25)
• Pages: 211-215
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.24-25.211
• Online since: September 2007
• Authors: Yan Wang, Shi Ming Wang, H. Zhou, De Jin Hu
• Keywords: Diamond Wheel, Dry-ECD Assisted Truing/Dressing, Macro/Micro Complex Feed Mechanism, Piezoelectric Ceramic Actuator

References

[1] Yan Wang, Xiao-jun Zhou, De-jin Hu: International Journal of Machine Tools & Manufacture Vol. 46 (2006), p.333.

[2] C. Zhang andY.C. Shin: International Journal of Machine Tools & Manufacture Vol. 42 (2002), p.825.

[3] Randeraat J Van，Setterington R E．Piezoelectric ceramics. London Mullard，1974 Voltage wave-form in dry-ECD.
