3D Simulation of Tunnel Collapse Consolidation and In Situ Monitoring Analysis

Abstract:

A shallow buried tunnel was collapsed during construction. According to the actual situation of the tunnel, different collapse consolidation schemes were put forward and corresponding three-dimensional finite difference numerical models were established and analyzed using FLAC3D software. Base on the 3D Simulation results, a collapse consolidation scheme was determined and constructed. The in-situ monitoring results of vault subsidence and convergence displacement were consistent approximately with the 3D Simulation results. The in-situ measured results were in line with the specification’s allowance and show that the consolidation effect of reinforced concrete casing arch and ahead grouting method is good. This could be referenced for similar engineering.

• Periodical: Advanced Materials Research (Volumes 243-249)
• Pages: 3551-3555
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.243-249.3551
• Online since: May 2011
• Authors: Zhi Min Chen, De An Zhao
• Keywords: Consolidation Scheme, Finite Difference Simulation, In Situ Monitoring, Tunnel Collapse

References

[1] HUANG Run-qiu, et al. Assessment and prediction of geohazards of the deep-lying long tunnel in the Yuanliangshan[J]. Journal of Chengdu University of Technology, 2001, 28(2): 111–115. (in Chinese)

[2] TÜRKMEN Sedat, ÖZGÜZEL Nuri. Grouting a tunnel cave-in from the surface: a case study on Kurtkulagı－irrigation tunnel, Turkey[J]. Tunnelling and Underground Space Technology, 2003(18): 365–375.

DOI: 10.1016/s0886-7798(03)00007-5

[3] FENG Wei-xing, KUANG Yong, CHEN Jian-jun. Case analysis of tunnel collapse[M]. Chengdu: Southwest Jiaotong University Press, 2002: 163–165. (in Chinese)

[4] HUO Yu-hua. Study on prevention of collapse accident in shallow buried highway tunnel and its countermeasures[J]. China Safety Science Journal, 2005, 15(7): 84–89. (in Chinese)

[5] FENG Xiuguo. The ground surface grouting method of tunnel collapsed area[J]. RAILWAY ENGINEERING, 1998, (2): 28－30. (in Chinese)

[6] Day M J. Karstic problems in the construction of Milwaukee's Deep Tunnels[J]. Environmental Geology, 2003, 45(6): 859－863.

DOI: 10.1007/s00254-003-0945-4

[7] SCHULLER H, SCHWEIGER H F. Application of a multilaminate model to simulation of shear band formation in NATM-tunnelling[J]. Computers and Geotechnics, 2002, 29: 501–524.

DOI: 10.1016/s0266-352x(02)00013-7

[8] SITHARAM T G, Madhavi Latha G. Simulation of excavation in jointed rock masses using a practical equivalent continuum approach[J]. International Journal of Rock Mechanics &Mining Sciences, 2002, 39: 517–525.

DOI: 10.1016/s1365-1609(02)00024-2

[9] STERPI D. Application of the FEM to the stability of shallow tunnels[J]. New Frontiers in Computational Geotechnics-Preceeding of 1st International Workshop on New Frontiers in Computational Geotechnics-banef, 2002: 14–15, 61–68.

[10] TRINH Q N, BROCH E, LU M. Three dimensional modeling of a tunnel cave-in and spiling bolt support[C]// ISRM International Symposium 2006, 4th Asian Rock Mechanics Symposium.
