Theoretical Analysis of SSCC Floor System of through Truss High-Speed Railway Bridges

Abstract:

In SSCC floor systems the concrete slab is composite with both steel stringers and crossbeams or only with stringers. The horizontal bending of the crossbeams of SSCC floor systems is not ignorable. From the deformation conforming condition, theoretical formulas for SSCC floor systems of double-railway bridges with two stringers are developed. The factors which influence the horizontal bending of crossbeams are discussed. Some conclusions are obtained. When the width of the SSCC floor system is given, the main factors which influence the horizontal bending of the crossbeams are the axial stress of the lower chords, the distance between the side stringers and the lower chords, and the continuous length of SSCC floor system. Increasing the horizontal inertia moment of crossbeams almost cannot reduce the horizontal bending stress of crossbeams. A slight horizontal rotation of the lower joints such as 10^-4 rad can release more than 3% crossbeam end horizontal bending moment.

• Periodical: Advanced Materials Research (Volumes 250-253)
• Pages: 1728-1733
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.250-253.1728
• Online since: May 2011
• Authors: Ye Zhi Zhang, Liang Chen
• Keywords: Composite Floor System, High-Speed Railway Bridge, Horizontal Bending, SSCC Floor System, Theoretical Analysis

References

[1] Zhang Yezhi: Comparison of bridge structures of railway through truss composite bridges. Journal of the China Railway Society Vol. 27-5 (2005), p.107 (In Chinese)

[12] Zhou Shengli and Lin Yachao: High speed railway steel truss bridge deck structural design and structural measure of reducing the noise. Foreign Bridges Vol. 1996-3 (1996), p.22 (In Chinese)

[3] Zhou Shengli and Lin Yachao: Xichuan bridge on the north land new railway of Japan. Foreign Bridges Vol. 1996-3 (1996), p.1 (In Chinese)

[4] U. Klansek and S. Kravanja: Cost estimation, optimization and competitiveness of different composite floor systems-Part 2: Optimization based competitiveness between the composite I beams, channel-section and hollow-section trusses. Journal of Constructional Steel Research Vol. 62 (2006), p.449

DOI: 10.1016/j.jcsr.2005.08.006

[5] Shun-ichi Nakamura, Yoshiyuki Momiyama, Tetsuya Hosaka and Koji Homma: New technologies of steel/concrete composite bridges. Journal of Constructional Steel Research Vol. 58 (2002), p.99

DOI: 10.1016/s0143-974x(01)00030-x

[6] Jacques Brozzetti: Design development of steel-concrete composite bridges in France. Journal of Constructional Steel Research Vol. 55 (2000), p.229

DOI: 10.1016/s0143-974x(99)00087-5

[7] Ye-zhi Zhang and Ying-hui Liu: Behavior of Tianxingzhou Yangtze Bridge of wuguang passenger dedicated line, edited by Xian-Yan Zhou, the 4th International Symposium on Lifetime Engineering of Civil Infrastructure, Science Press (2009).
