Fractal Research on Cracks of Reinforced Concrete Beams with Different Aggregates Sizes

Abstract:

Under the concentrated loads, the crack evolutions of reinforced concrete experimental beams (RCEB) with three different aggregate sizes are studied. Using fractal theory, the generation, development and distribution of the cracks on the RCEB are analyzed. The results show that the cracks on the RCEB have fractal characteristics obviously. By studying the fractal dimension of the cracks, the aggregate sizes have significant effect to the cracks on the RCEB. The relationships of the fractal dimensions of the crack evolution in loading processing and loads meet the power function laws. The researching results of this paper provide a new theoretical basis for selecting the appropriate aggregate size to improve the strength of reinforced concrete beams.

• Periodical: Advanced Materials Research (Volumes 250-253)
• Pages: 1818-1822
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.250-253.1818
• Online since: May 2011
• Authors: Hong Quan Sun, Jun Ding, Jian Guo, Dong Liang Fu
• Keywords: Aggregates Size, Crack, Fractal Dimension, Fractal Geometry

References

[1] Benoit B. Mandelbrot, The Fractal Geometry of Nature, W. H. Freeman and Company, San Francisco: 1982. 361~366.

[2] Michael Barnsley, Fractals Everywhere, Academic Press Orlando. FL.1988, 172~ 247.

[3] Heping Xie. Fractals in Rock Mechanics. A. A. Balkema Publishers, Netherlands. 1993.

[4] Sun Hongquan. The study of fractal interpolation on rectangular area. Acta Mathematica Sientia[J], 2009(3). 773~783. (in Chinese).

[5] Chen Yu, Chen Ling. Fractal geometry [M], Beijing, Earthquake Press. 1998. (in Chinese).

[6] Xie Heping, Fractal Description of Rock Joints, Chinese Jounal of Geotechnical Engineering[J], 1995(1), 18~23. (in Chinese).

[7] Wang Jin'an , Xie Heping , Fractal Evolution of Surface Roughness and Mechanical Behavior of Rock Joints Under Shearing, Chinese Jounal of Geotechnical Engineering[J], 1997 (4). 2~9. (in Chinese).

[8] Li yanyan, Experimental Research on Behaviors of Reinforced Concrete Beams with 500MPa Steel Bars[D], Tianjin University. 2007.12. (in Chinese).

[9] Cao Maosen, REN Qingwen , Zhai Ailiang, Zhang Jing. Experimental study on fractal characterization in damages of concrete structures, Rock and Soil Mechanics[J], 2005(10), 1570~1574. (in Chinese).

[10] Rong Xian, LIU Yuan, Liu Ping, Qiao Ke. Experimental Research on Diagonal Crack of Reinforced Concrete Simple Beam with High-strength Stirrup Based on Fractal Theory, Journal of Hebei University of Technology[J], 2008(2), 77~82. (in Chinese).

[11] Wang Tiecheng, Yang Jianjiang, Fang Peng. Fractal geometry analysis of appearance and propagation of crack in concrete structure, Journal of Dalian University Of Technology[J], 1997(s1), 77~81. (in Chinese).
