Fractal Approach on Quantitative Analysis of Micro Pore Structure of Isotropic Consolidated Clay

Abstract:

The micro pore structure of isotropic consolidated clay was studied by using a scanning electron microscope (SEM). A digital imaging technique was applied to analyze the evolution of size, number of pores and their distributions in the process of isotropic consolidation according to the SEM images. Based on the fractal concepts of Koch curve and Sierpinski carpet, the Koch fractal dimension Dk and the Sierpinski fractal dimension D_s of soil pores are obtained from the measured data. The variations of both D_k and D_s following the change of micro pore parameters and mechanical properties of clay are investigated. The results show that the porosity and pore size decreases as the consolidation pressure increases, and the range of pore size becomes narrower. D_k reflects the degree of irregularity of the pore-solid interface in soil, and the larger the D_k the more irregular the soil pore profile. The distribution of D_k was found in agreement with a total normal distribution in soil pore. The magnitude of D_s reflects the variation of porosity of clay under isotropic consolidation. Large fractal corresponds to large consolidation pressure and small porosity. D_s displays a significant linear regression relationship with porosity, consolidation pressure, consolidation deformation of clay and an exponential growth relationship with permeability coefficient of clay. Both Dk and D_s is sensitive to isotropic consolidation of soil and they may be cited as useful indicators for soil consolidation.

• Periodical: Advanced Materials Research (Volumes 250-253)
• Pages: 1846-1851
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.250-253.1846
• Online since: May 2011
• Authors: Xiao Xuan Liu, Ji Ru Zhang
• Keywords: Clay, Fractal Approach, Isotropic Consolidation, Micro-Pore Structure, Quantitative Analysis

References

[1] Osipov,J.B, Sokoloy,B.K, Proceedings of the International Symposium on Soil Structure, Gothenburg, Sweden, 1973, 21~29.

[2] Tovey,N.K, Proceedings of the International Symposiurn on Soil structure, Gothenburg, Sweden, 1973,50~59.

[3] Bing Shi, Hongtao Jiang, Chinese Journal of Rock Mechanics and Engineering, 20(6), 2001, 864~870. (In Chinese)

[4] Jiru Zhang, Li Huang, Acta Pedologica Sinica, 45(2), 2008, 207~215. (In Chinese)

[5] Jiru Zhang, Jie Zhu, Journal of Hydraulic Engineering, 39(4), 2008, 394~400. (In Chinese)

[6] Jiru Zhang, Gaoliang Tao, Journal of Shanghai Jiaotong University (Science), 16(1), 2011, 78~82.

[7] Jiru Zhang, Jie Zhu, Journal of Wuhan University of Technology, 30(4), 2008, 80~83. (In Chinese)
