Theoretical and Experimental Study on Cable-to-Irder Anchorages in Long-Span Cable-Stayed Bridges with Steel Box Girder

Abstract:

Cable anchorages are among the most important elements in a cable-stayed bridge, which are complex in structure and bear heavy load. There are three main forms in anchorage zone between girder and cable in modern long-span cable-stayed bridge with steel box girder, which are ear-plate form, anchor-box form and anchor-plate form. Combining theoretical analysis with the static test, static behavior and stress transfer pathway of three typical cable-to-girder anchorages were analyzed, and the differences of stress distribution and stress concentration among anchorage zones were pointed out. Based on the Von.Mises strength criterion, bearing safety of three typical cable-to-girder anchorages was evaluated. Finally, the measures to reform stress distribution and reduce stress concentration are discussed. Some useful conclusions were obtained, which would benefit the design of cable-to-girder anchorages.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 1315-1318
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.1315
• Online since: May 2011
• Authors: Xing Wei, Jun Li
• Keywords: Bearing Safety, Cable-Stayed Bridge, Cable-to-Girder Anchorage, Static Behavior, Stress Distribution

References

[1] Li Xiaozhen, Cai Jjing, Qiang Shizhong: Engineering Mechanics,Vol.21(2004),p.84. (In Chinese)

[2] Niels J. Gimising.Cable Supported Bridges-Concept & Design.(China Communications Press, Beijing 2002) (in Chinese)

[3] Wei Xing, Li Xiaozhen, Li jun, Qiang shizhong. In: Progress in safety science and technology, edtied by Li Shengcai, Wang Yajun, Huang Ping: Vol.V. Beijin: Science Press( 2005).

[4] Jin Zenghong: Foreign Highway, Vol.19(1999), pp.8-13. (in Chinese)

[5] Liu Qingkunan, Wang Xinmin, Qiang Shizhong: China Civil Engineering Journal,Vol. 34(2001), p.50. (In Chinese)

[6] Su Shangen, Xu Hongliang: China Railway Science, Vol. 24(2003),p.94. (in Chinese)

[7] Chen Kaili, Zheng Gan: China Railway Science, Vol. 26(2005),p.28. (in Chinese)

[8] Hou Wenqi, Ye Meixin: Steel Structures, Vol.17(2002),p.23. (In Chinese)
