Experimental Study on Three-Dimensional Base-Isolated Model with 3DIB

Abstract:

A new 3-dimensional isolation bearing (3DIB), which is combined with lead rubber bearing (LRB) and disk spring bearing (DSB), is introduced in this paper. A series of shaking table tests of the 1/2 scale fixed-base and 3DIB base-isolated model were compared to confirm the validity of the 3DIB. Results show that the 3DIB can isolate 3-dimensional earthquake energy remarkably. Large displacement of the 3DIB base-isolated system occurred on the isolation layer, and the inter-story deformation of the superstructure changed slightly. The horizontal acceleration responses of 3DIB model decreased more than 60% and the vertical acceleration responses decreased more than 50% under the severe earthquake of 0.4g in PGA input, which confirmed that 3DIB could isolate both the horizontal and vertical earthquakes obviously.

You might also be interested in these eBooks

Advances in Civil Engineering, CEBM 2011

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 255-260)

Pages:

2325-2329

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.255-260.2325

Citation:

Cite this paper

Online since:

May 2011

Authors:

Ya Min Zhao, Jing Yu Su, Ming Lu

Keywords:

Horizontal Isolation, Seismic Response, Shaking Table Test, Vertical Isolation

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] F. Naeim and J. M. Kelly. Design of Seismic Isolated Structures-From Theory to Practice. John Willy &Sons, INC, New York(1999).

Google Scholar

[2] J. M. Asher, S. N. Hoskere and R. D. Ewing. Seismic Performance of the Base-isolated USC University Hospital in the 1994 Northridge Earthquake. Proceedings of Joint ASME/JSME Pressure Vessels and Piping Conference, Seismic Shock and Vibration Isolation, Vol. 319(1995), pp.147-154.

Google Scholar

[3] Code for Seismic Design of Building (GB 50011-2001). China Architecture & Building Press, Beijing, 2001.

Google Scholar

[4] T. Shimada, T. Fujiwaka, and S. Moro. Study on Three-dimensional Seismic Isolation System for Next-Generation Nuclear Power Plant: Hydraulic Three-dimensional Base Isolation System. Proceedings of Pressure Vessels and Piping Conference, ASME. USA: San Diego, California. Vol.486 (2004), pp.35-42.

DOI: 10.1115/pvp2004-2931

Google Scholar

[5] A. Kashiwazaki, R. Mita, and T. Enomoto, et al. Three-dimensional Base Isolation System Equipped with Hydraulic Mechanism. Transactions of the Japan Society of Mechanical Engineers, Vol.66 (1999), pp.146-151.

DOI: 10.1299/kikaic.66.2616

Google Scholar

[6] K. Inoue, M. Morishita, and T. Fujita. Development of Three-dimensional Seismic Isolation Technology for Next Generation Nuclear Power Plant in Japan. Proceedings of Pressure Vessels and Piping Conference, ASME. USA: San Diego, California. Vol.486 (2004), pp.29-34.

DOI: 10.1115/pvp2004-2930

Google Scholar

[7] Y.M. Zhao. Shaking Table Tests and Theoretical Study on Three-dimensional Base-Isolated System. Dissertation of Beijing University of Technology, Beijing, 2007.

Google Scholar

[8] Y.M. Zhao, J.Y. Su, X.Y. Zhou, Y.K. Sui. Shaking Table Test and Numerical Analysis of Vertical-isolated Building Model with Combined Disk Spring Bearing. Journal of Building Structures, vol.29 (2008), pp.99-106.

Google Scholar
