The Application of Crushed Rock Materials upon Railway Embankments in Permafrost Regions

Abstract:

Crushed rock materials had been utilized extensively upon embankments, termed as crushed rock embankment (CRE), along the Qinghai-Tibet Railway in permafrost regions. Based on a long-term monitoring system along the railway, thermal stability and deformation characteristics and mechanisms of CRE were analyzed by field monitoring datasets from 2005 to 2009. The thermal stability analyses indicated that permafrost tables beneath CRE all had upwards movements but to varying degrees. For U-shaped crushed rock embankment (UCRE), the thermal stability of underlying permafrost kept well; along with permafrost table moving upwards, the shallow ground temperatures beneath the embankment decreased obviously while deep ground temperatures kept almost constant. For crushed rock revetment embankment (CCRE), the cooling effect was effective in cold permafrost regions. But in warm permafrost regions, the shallow permafrost beneath the embankment had no obvious cooling trend while the deep permafrost had a slight warming trend. The deformation analyses indicated that CREs experienced frost heave in permafrost regions with mean annual ground temperature (MAGT) < -1.5 °C but settlement in permafrost regions with mean annual ground temperature > -1.5 °C. The magnitudes of both heave and settlement were not significant. Since the better thermal stability of underlying permafrost, it was inferred that the settlement of CRE mainly originated from compression of warm and ice-rich permafrost layer near permafrost table.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 4027-4033
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.4027
• Online since: May 2011
• Authors: Yan Hu Mu, Wei Ma, Zhi Zhong Sun, Yong Zhi Liu
• Keywords: Crushed Rock Materials, Embankment Deformation, Permafrost, Railway Embankment, Thermal Stability

References

[1] S.A. Harris and D.E. Pedersen: Permafr. Perig. Processes, 9(1998), p.107

[2] G.P. Mikhailov: Transportation Construction 12 (1971), p.32.

[3] G.D. Cheng and B.L. Tong, in: Proceedings of the 3rd International Conference on Permafrost, vol. 2. National Research Council of Canada, Ottawa, 1978, p.199.

[4] G.S. Wang, Q. Lin, H.J. Jin, in: Proceedings of the 5th Chinese National Conference on Glaciology and Geocryology (Vol.1), Lanzhou: Gansu Culture Press, 1996. p.377.

[5] D.J. Goering and P. Kumar: Cold Reg. Sci. Tech., 24 (1996), p.57.

[6] Cheng, G.D.: ACTA Geogr. Sin., 39(1984), p.185.

[7] Jin, H.J., Zhao, L., Wang, S.L., Jin, R.: Sci. in China Series D: Earth Sci., 49(2006), p.1170.

[8] Cheng, G.D.: J. of Glaciology and Geocryology, 2(1980), p.39.

[9] Jin, H.J., Li, S.X., Wang, S.L., Zhao, L.: ACTA Geogr. Sin., 55(2000), p.161.

[10] Qiu, G.Q., Cheng, G.D.: Permafr. Perig. Processes, 6(1995), p.3.

[11] Tong, C.J., Wu, Q.B.: Cold Reg. Sci. Tech., 24(1996), p.101.

[12] Wu, Q.B., Zhang, T.J., Liu, Y.Z.: Global and Planetary Change, 72(2010), p.32.

[13] Cheng, G.D., Wu, T.H.: J. Geophys. Res, 112(2007), p.1.

[14] Jin, H.J., Yu, Q.H., Wang, S.L., Lv, L.Z.: Cold Reg. Sci. Tech., 53(2008), p.317.

[15] Wang, S.L., Jin, H.J., Li, S.X., Zhao, L.: Permafr. Perig. Processes, 11(2009), p.43.

[16] Wu, Q.B., Liu, Y.Z.: Cold Reg. Sci. Tech., 38(2004), p.85.

[17] Cheng, G.D., Wu, Q.B. and Ma, W.: Sci. in China Series E, 52(2008), p.530.

[18] Ma, W., Cheng, G.D. and Wu, Q.B.: Cold Reg. Sci. Tech., 59(2009), p.3.

[19] Cheng, G.D., Lai, Y.M., Sun, Z.Z. and Jiang, F.: Permafr. Perig. Processes, 18(2007), p.151.

[20] Y.H Mu, W. Ma, Y.Z. Liu, Z.Z. Sun: Cold Reg. Sci. Tech., 62(2010), p.160.

[21] Wu, Q.B., Zhao, S.Y., Ma, W., Liu, Y.Z. and Zhang, L.X.: Chinese J. of Geotechnical Engineering, 27(2005), p.1386.

[22] Zhang, J.M., Liu D. and QI J.L.: China Railway Science, 28(2007), p.12.
