Development of the Small-Sized Equipment for Detecting Short-Wave Irregularity of the Top Rail

Abstract:

Short-wave irregularity of top rail has great influence on status of both train operation and rail track. Based on the non-contact measurement principle and the virtual instrument development platform with powerful function, the paper designs the system for detecting short-wave irregularity of the top rail based on virtual instrument with the eddy current displacement sensor. The system can realize online real-time display, analysis, processing, storage and search of historical data and printing. With this method, we can detect the smoothness of rails and provide a better scientific basis for making a plan to guide the daily work of track maintenance.

• Periodical: Advanced Materials Research (Volumes 255-260)
• Pages: 4039-4042
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.255-260.4039
• Online since: May 2011
• Authors: Yue Lei He, Wen Liang Zhu, Ji Kun, Bin Zeng, Chen Yang
• Keywords: Detect, Rail, Short-Wave Irregularity

References

[1] MENG JIA, GAO XIAORONG.: Railway Quality Control,2005(1),34~36.

[2] D.R. HolfeId and G.E Ghafe.: RailwayTrack&Structures.1989,(11)

[3] WANG JUNFENG SONG WENAI.: Control & Automation. 2007(23),156~158.

[4] LIANG ZHIGUO, SUN XIAYU. : Measurement & Control Technology,2003,22(12): 1~4.

[5] LUOLIN. High Smoothness: Chinese Railways,2000,9(10):8~12.

[6] National Instrument Corporation, LabVIEW User Manual, 2008.

[7] Du Heting; Gao Linkui; Fan Geping.: China Railway Science,1997,18(1):79~90.
