A Numerical Computation Method for Pipe Cooling Concrete Temperature Field

Abstract:

Based on the coupled thermal-fluid pipe element, a numerical computation method for concrete temperature field with pipe cooling is proposed in this paper. This method has both the high efficiency of equivalent negative heat source method and the high precision of cooling pipe discrete element method. The theory and detailed steps of the method are introduced. Then the validity and accuracy of the proposed method are demonstrated by an engineering example of concrete ship lock which is better consistent with the measured results.

• Periodical: Advanced Materials Research (Volumes 261-263)
• Pages: 137-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.261-263.137
• Online since: May 2011
• Authors: Yu Song Jiang, Li Tan Pan, Chao Su
• Keywords: Concrete Temperature Field, Numerical Computation, Pipe Cooling, Thermal-Fluid Pipe Element

References

[1] U.S. Department of the Interior, Bureau of Reclamation: Cooling of concrete dams(China Water Resources & Electric Power Press, Beijing,1958), in Chinese.

[2] B.F. Zhu: Temperature stress and control of mass concrete(China Electric Power Press, Beijing,1999), in Chinese.

[3] B.F. Zhu: Theory and application of FEM (China WaterPower Press, Beijing,1998), in Chinese.

[4] B.F. Zhu: Equivalent equation of heat construction in mass concrete considering the effect of pipe cooling. Chinese SHUILI XUEBAO Vol. 3(1999), pp.28-34, in Chinese.

[5] B.F. Zhu: Effect of cooling by water flowing in nonmetal pipes embedded in mass concrete. Journal of Construction Engineering and Management Vol. 1(1999), pp.61-38.

DOI: 10.1061/(asce)0733-9364(1999)125:1(61)

[6] B.F. Zhu and J.B. Cai: Finite element analysis of effect of pipe cooling in concrete dams. Journal of Construction. ASCE(1989), pp.487-498.

[7] B.F. Zhu: On pipe cooling of concrete dams. Chinese SHUILI XUEBAO Vol. 41( 2010), pp.505-513, in Chinese.

[8] Y.M. Zhu, Z.Q. XU, J.R. He and J.B. Zhang: A calculation method for solving temperature field of mass concrete with cooling pipes. Journal of Yangtze River Scientific Research Institute. Vol. 20( 2003), pp.19-22, in Chinese.

[9] Y.M. Zhu and Z.L. You: Analysis of water cooling pipe system in mass concrete. In: Proceedings of the 4th International Conference on Dam Engineering, Published by: A.A. Balkema Publishers, a member of Taylor & Francis Group plc, (2004) London, UK.

[10] Y.Z. Liu, Y.M. Zhu and G.X. Zhang: Feedback Analysis and Study on In-situ Cooling Effect of PE Pipe in Zhougongzhai Arch Dam. Chinese Water Power Vol. 33(2007), pp.40-43, in Chinese.

[11] ANSYS, inc. Thermal Analysis guidebook of ANSYS 2000. (2000).
