Grain Growth Evaluation in HAZ of Welded Pipes Using Dimensionless Parameters and Optimum Pre-Exponential Constant for Seam Weld and Seamless Pipes

Abstract:

Kinetic strength in grain growth is evaluated for HAZ of welded pipes. Austenite grain growth is dependant on the thermal cycle and the material properties. In this research the influence of thermal cycle is evaluated using characteristic time constant and characteristic temperature. These dimensionless parameters were calculated for the points lying in HAZ using temperature/time profile derived from Rosenthal equation for the heat transfer. The grain growth is assumed diffusion controlled and Arrhenius temperature dependency is applied for the rate of growth in grains. In an experimental investigation the welded pipes were sectioned longitudinally and the grain size in parent metal and HAZ were measured based on ASTM E 112 by using Planimetric Counting. The obtained data was compared with the result of the model and the appropriate kinetic constant which is calibrated the equation of grain growth is introduced for the seam weld and seamless pipes.

• Periodical: Advanced Materials Research (Volumes 264-265)
• Pages: 284-289
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.264-265.284
• Online since: June 2011
• Authors: M.E. Aalami-Aleagha, S. Rasaee
• Keywords: Grain Growth, Kinetic Strength, Non-Isothermal Heating Cycle, Seamless Pipe

References

[1] J.C. Ion and K.E. Easterling and M. F Ashby: A second report on diagrams of microstructure and hardness for heat-affected zones in welds, Acta Metall. Vol. 32 No. 11 (1984), p.1949-(1962).

DOI: 10.1016/0001-6160(84)90176-7

[2] J.C. Suarez and F. Molleda and J.M. Gomez de Saazar: Modeling of grain growth during arc welding of high strength low alloy steels, Materials Characterization Vol. 28 (1992), pp.3-13.

DOI: 10.1016/1044-5803(92)90024-c

[3] Y. Shi and D. Chen and Y. Lei and X. Li: HAZ microstructure simulation in welding of a ultra fine grain steel, Computational Materials Science, Vol. 31 (2004), pp.379-388.

DOI: 10.1016/j.commatsci.2004.04.004

[4] R.M. Miranda and M.A. Fortes: Austenite grain growth, microstructure and hardness in the heat-affected zone of a 2. 25Cr-1Mo steel, Mat. Sci. and Eng., Vol. A 108 (1989), pp.1-8.

DOI: 10.1016/0921-5093(89)90399-7

[5] D.L. Bourell and W. Kaysser: Effect of nonisothermal heating or cooling on grain growth, Acta Metall, Vol. 41 No. 10 (1993), pp.2933-2937.

DOI: 10.1016/0956-7151(93)90107-4

[6] J.P. Drolet and A. Galibois: Acta Metall. Vol. 16 (1968), p.1387.

[7] M. Shome and O.P. Gupta and O.N. Mohanty: A modified analytical approach for modeling grain growth in the coarse grain HAZ of HSLA steels, Scripta Materialia, Vol. 50 (2004), pp.1007-1010.

DOI: 10.1016/j.scriptamat.2003.12.030

[8] D. Rosenthal and J. Weld, 20: 220s, (1941).

[9] S. Kou: Welding Metallurgy, 2nd edition, John Wiley & Sons Inc, (2003).

[10] C.M. Adams: Weld Jr., 37: 210s, (1958).
