Nonlinear Vibration Characteristics Analysis of Transmission Gears

Abstract:

In allusion to a truck transmission gears, a nonlinear vibration model of transmission gears was constructed based on the theory of gear system dynamics and nonlinear dynamics. Basing on the computing platform Matlab and using the Runge-Kutta method to calculate the time history response of gear vibration when the gap exists, and the case of non-resonant and load gear backlash vibration frequency of gear changes were studied. The results of this paper have an important significance to improve the movement of transmission gears to pass accuracy, reduce noise, reduce failures and increase gear life.

• Periodical: Advanced Materials Research (Volumes 282-283)
• Pages: 633-636
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.282-283.633
• Online since: July 2011
• Authors: Qin Man Fan, Yong Hai Wu
• Keywords: Gear, Transmission, Vibration

References

[1] Sopouch M, Schaffner T, Vock C. NVH Analysis of Transmission and Drivelines . International AST User Meeting. 2005, p.100~111.

[2] Curtis S, Pears J. An analytical Method to Reduce Gear Whine Noise, Including Validation With Test Data . SAE 01-1819. (2005).

DOI: 10.4271/2005-01-1819

[3] Forcelli A, Grasso C, Pappalardo T. The Transmission Gear Rattle Noise: Parametric Sensitivity Study . SAE 01-1225. (2004).

DOI: 10.4271/2004-01-1225

[4] Lahey H P, Steffens C. Simulation Method for Gear-train NVH Assessment and Optimization . SAE01-1593. (2003).

[5] Excite Timing Drive and Excite Designer User Manual[M] . Graz: AVL Advanced Simulation Software Department, (2007).
