Based on Risk Source Pipe Leakage Emergency Device and Sealing Method Research

Abstract:

Along with the rapid development of chemical industry and the progress of science and technology, there exist safety risks for a large number of risk source pipelines. On the basis of the conventional containment measures for risk source leakage, this paper designed two types of emergency devices and corresponding rapid closure methods. One type is the pipeline leak sealing airbag inside the risk source. It is constituted by sealing institutions, diversion institutions, keep institutions and fixed institution. During the work, the sealing airbag gets inflated to realize the rapid closure inside in the piping. It is applicable to the sealing of the heat, water supply, the chemical pipeline, and even large pipe leakages. It also provides the diversion function. The second type the external leakage sealing gasbag for the risk source pipelines. It is compositioned by the belt type rubber air mattress,left and right sides of adjustable bits semi-manipulator mechanism. It is mounted using the belt type rubber layers of tilt superposition around in pipe outside. When needed the air gets inflated inside the gasbag, making each layer of air cushion tension bridle and mutual extruding, to execute rapid closure for the pipeline leakage. These two types of devices are easy to carry, require low professional training, while are highly efficient for the fast closure of the pipeline leakages.

• Periodical: Advanced Materials Research (Volumes 287-290)
• Pages: 2834-2839
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.287-290.2834
• Online since: July 2011
• Authors: Hong Wei Yan, Zi Ming Kou, Juan Wu, Xian Hui Wang
• Keywords: Leak, Rapid Sealing, Risk Source, River Diversion, Rubber Gasbag, Tanks

References

[1] Li Pingquan: Oil and Gas Pipelines Failure and the Typical Case,Oil & Gas Storage and Transportation. Vol.24.(2005), p.36. In Chinese.

[2] J.z. Meng: Oil and Gas Field Surface Engineering,Vol.28.(2009),p.83. In Chinese.

[3] Hu Yiwei:Dynamic sealing technology Leakage and Plugging (Defense Industry Press, In Chinese, 1998).

[4] V.M. Fthenakis:A.Rev.Critique.Compassion.Models.Journal of Loss Prevention in the Process Industries, (1999),p.525

[5] Williams B R:The prediction of separated flow using a viscous-inviscid interaction method，The Aeronautical,Vol.89. (1985), p.181.

DOI: 10.1017/s0001924000014779

[6] Zhao Guangyao:Equipment leakage prevention(Metallurgical Industry Press, In Chinese, 1986)

[7] Zhang Ji:Conduit leakage and leak sealing clamp,Petrochemical Equipment.Vol.34.(2005), p.35

[8] Yeoh.O.H:Characterization of elastic properties of carbon blak filled rubber vulcanization，Rubber Chemical and Technology, Vol.63.(1990),p.780.
