Influences of New Electrical Material on Transient Heat Transfer in IMCCR

Abstract:

A new kind of alloy (conductor for electric and magnetic), is proposed in this paper, which applied in induction motor rotor bars, and a kind of induction motor with compound cage rotor(IMCCR) is obtained. By using the electromagnetic-thermal coupling analysis method, the transient temperature field of an IMCCR is numerically analyzed, and the transient thermal process of motor operating with blocked rotor for 10s and then stopped for 10min natural cooling is calculated. The heat diffusion of stator equivalent windings and the double-directions heat transmission processes in stator are analyzed. Based on which, the influences of rotor material permeability and conductivity on motor performance are studied. Comparing with the normal nonmagnetic material, the alloy could improve motor performance significantly while ensure motor thermal performance, which indicates the wide application of such alloy in electrical machines.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 1669-1673
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.1669
• Online since: July 2011
• Authors: Jun Ci Cao, Wei Li Li, Xiao Chen Zhang, Yi Huang Zhang
• Keywords: Alloy, Electromagnetic, Heat Transfer, Motor

References

[1] Jinhwan Jung and Kwanghee Nam. "A Vector Control Scheme for EV Induction Motors with a Series Iron Loss Model," IEEE Transactions on Industrial Electronics, Vol. 45, No. 4, pp.617-624, 1998.

DOI: 10.1109/41.704890

[2] Dejun Yin, Sehoon Oh, and Yoichi Hori. "A Novel Traction Control for EV Based on Maximum Transmissible Torque Estimation", IEEE Transactions on Industrial Electronics, Vol. 56, No. 6, pp.2086-2094, (2009)

DOI: 10.1109/tie.2009.2016507

[3] D. F. Gosden, B. J. Chalmers, and L. Musaba, "Drive System Design for an Electric Vehicle Based on Alternative Motor Types," Power Electronic and Variable-Speed Drives, p.710~715, October 1994.

DOI: 10.1049/cp:19941052

[4] T. Aho, V. Sihvo, J. Nerg and J. Pyrhonen, "Rotor Materials for Medium-Speed Solid-Rotor Induction Motors". Proceedings of IEEE International Electric Machines and Drives Conference, Vol. 1, pp.525-530, May 2007.

DOI: 10.1109/iemdc.2007.382722

[5] W. R. Finley and M. M. Hodowanec, "Selection of copper versus aluminum rotors for induction motors," IEEE Transactions on Industry Applications, Vol. 37, pp.1563-1573, Nov.-Dec. 2001.

DOI: 10.1109/28.968162

[6] Weili Li, Junci Cao and Xiaochen Zhang, "Electro-thermal Analysis of Induction Motor with Compound Cage Rotor Used for PHEV," IEEE Trans. Ind. Electron, vol. 57, no. 2, pp.660-668, Feb 2010.

DOI: 10.1109/tie.2009.2033088

[7] J. Xypteras and V. Hatziathanassiou, "Thermal analysis of an electrical machine taking into account the iron losses and the deep-bar effect," IEEE Transactions on Energy Conversion, 1999, vol. 14, pp.996-1003.

DOI: 10.1109/60.815019

[8] V. Hatziathanassiou, J. Xypteras and G. Archontoulakis, "Electrical-thermal coupled calculation of an asynchronous machine," Archiv fur Electrotechnik, 1994, vol. 77, pp.117-122.

DOI: 10.1007/bf01578534
