Research on a New Flexible Acceleration and Deceleration Algorithm with Continuous Jerk

Abstract:

Control of the motion process of acceleration/deceleration (Acc/Dec) is one of key complicated problems in CNC system development. The excellent Acc/Dec control can improve the processing precision. The traditional Acc/Dec algorithms such as the linear and the exponential are not suitable for high speed motion because there would be flexible impacts existing in feed motion, especially that the jerk of the S-shape curve Acc/Dec is discontinuous. A new flexible Acc/Dec algorithm for high speed motion system based on the squared sine function is introduced. The modeling of the Acc/Dec algorithm with Trigonometric Function Squared Sine(TFSS) shape curve is constructed.In this algorithm, the sine curve in jerk, acceleration, velocity and displacement are all continuous. The simulation experiments result demonstrate that the Acc/Dec algorithm with TFSS shape curve is a new method of continuous Jerk for the design flexible Acc/Dec.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 286-289
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.286
• Online since: July 2011
• Authors: Jian Ren Sun, Chi Bing Hu
• Keywords: Deceleration Algorithm, Flexible Acceleration, High Speed Motion, Jerk, Trigonometric Function Squared Sine Shape Curve

References

[1] Jianhua Hu, Wenhe Liao, Rurong Zhou.Research and Comparison for Several Curves of Acceleration and Deceleration in CNC Systems[J]. Nanjing University of Aeronautics and Astronautics. 1999,31(6),pp.706-711.

[2] Mei Shuai, Xiaoyan Miao, Yuan Liu, Xiaochun Wang, The Algorithm of Non impact Fast Feed Control in Five Axis CNC System[J]. Mechanical Science and Technology(1998),17(6),pp.950-952.

[3] Erkorkmaz K, Altintas Y. High speed CNC system design. Part I. Jerk limited trajectory generation and quintic spline interpolation [J].Int J Mach Tools Manufact(2001),41(2),pp.1323-1345.

DOI: 10.1016/s0890-6955(01)00002-5

[4] Xingui Guo. Research on High Accuracy Interpolation Algorithm for High Speed Cutting [D].Shanghai: Shanghai Jiaotong University,2002.

[5] Weiren Zhang. Acceleration /Deceleration Planning with Jerk Limitation for Multi-Axis Motion Control [D].Taiwan: National Central University,2002.

[6] S. Macfarlane, E.A. Croft.Design of Jerk Bounded Trajectories for On-Line Industrial Robot Applications[J].Proceedings 2001 ICRA. IEEE International Conference on Robotics and Automation, Vol.1(2001),pp.979-984.

DOI: 10.1109/robot.2001.932677

[7] Jiawen Li, Zongyu Chen, Congxin Li. Trigonometric Function Acceleration & Deceleration Algorithm Based on Function Approximation[J]. Machine Tool and Hydraulics, 2006(3),pp.66-67.

[8] Guoyong Zhao. Research on ACC/DEC Control,Servo control and Contour Control of CNC System[D]. Dalian: Dalian University of Technology,2006.

[9] Guoshun Ji. Study on Kinetic Control Technologies for High Speed CNC Leather Cutting [D]. Hangzhou: Zhejiang University,2007.
