An Analytic Iteration Method of Geometrical Nonlinear Analysis for Frame Structures and its Application Program Research

Abstract:

Static method and energy method are two mainly solution methods for structure calculation presently. Static method often appears insoluble complicated transcendental equations and continues hardly. Energy method can solve force analysis of complicated structure and it is a widely used method at present, but in general it is not exact. In this article, analytic iterative method is a calculation method of analyzing geometrical nonlinear of frame Structures, considering the influence of geometrical nonlinear in structure calculation, on foundation of the analytic method that expressed with deflection equation of pressure column with geometry parameter expression with the combination of traditional linear analysis method. And a calculating application program is written to calculate displacement and force of frame structure in the environment of MATLAB language in order to apply conveniently. Because this method is on basis of analytic method, its results have sufficient accuracy. At last, there is an example to explain.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 3305-3310
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.3305
• Online since: July 2011
• Authors: Lu Sun, Rui Zhao, Rui Li
• Keywords: Analytic Iteration Method, Application Program, Geometrical Nonlinear, RC Frame Structure, Structures Engineering

References

[1] Yuqiu Long and Shihua Bao. Structural Mechanics lesson. Higher Education Press. (2000).(in Chinese).

[2] S.P. Timoshenko and D.H. Young. Theory of Structures. McGraw-Hill.(1965).

[3] R.Narayanan. Steel Framed. Structures-Stability and Strength Elsevier applied science publishers. (1985).

[4] K.J. Bathe and E.L. Wilson. Numerical Methods in Finite Element Analysis. Prentice- Hall, Inc. (1976).

[5] Wancheng Liu. Analytical Method for Nonlinear Problems Bar.Harbin: Northeast Forestry University Press. (2002) (in Chinese).

[6] Suxia Kou. Calculating Frame Elastic Layer Displacement Affected by the Vertical Load.Low Temperature Architecture Technology. Vol. 1 (2005), pp.68-69. (in Chinese).

[7] Jiawen Wang, Hao Wang and Hai Liu. MATLAB7.0 Programming Fundamentals. Beijing: Machinery Industry Press. (2005)(in Chinese).

[8] Hongxing Qiu, Ganping Shu, Shuangyin Cao and Baogang Mu. Architectural Structural design. Nanjing: Southeast University Press. (2002) (in Chinese)
