A Study of Springback of Sheet Metal Formed Parts Using ANSYS

Abstract:

Springback is one of main reason for inaccuracy of sheet metal formed product. Therefore prediction of springback is very important for production of precise products. Springback is an elastic material recovery after unloading of the forming tools, and causes variations and inconsistencies of final part dimensions. This is affected by various parameters involved in the process of sheet metal forming. The main aim of this paper is to investigate the springback of finished part by analysing and controlling the effects of the control parameters on the springback of advanced high strength steels (AHSS). This is done by modelling a deep-drawing process and analysing the results as determined on ANSYS finite element analysis software.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 381-384
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.381
• Online since: July 2011
• Authors: Xuan Zhi Wang, Syed H. Masood, Daron Ng, Omar Dawwas
• Keywords: AHSS, ANSYS, Finite Element Analysis (FEA), Sheet Metal Stamping, Springback Prediction

References

[1] A. Tang, et al: AIP Conference Proceedings Vol. 778 (2005), pp.314-321.

[2] H.S.S. Aljibori and A.M.S.S, Hamouda: Eur. J. Sci. Res. Vol. 33 (2009), pp.57-69.

[3] W.M. Chan, H.I. Chew, H.P. Lee and B.T. Cheok: J. Mat. Process. Tech. Vol. 148 (2004), pp.15-24.

[4] T. Da Silva Botelho, E. Bayraktar and G. Inglebert: Int. J. Comput. Mater. Sci. Surf. Eng. Vol. 1 (2007), pp.197-213.
