Application of Numerical Simulation in Stamping Process of Complex Box-Type Parts

Abstract:

Due to the recent development both in the numerical simulation technology and computer technology, the role of numerical simulation in sheet forming industry has been continuously increasing in recent years. This paper describes the application of numerical simulation technology in the forming process of a complex box-type part with Dynaform and gives a fairly accurate forecast of defects that may appear in the forming process. Prediction of the effect of design parameters such as blank holding force and drawbeads on forming quality is investigated. The study indicates that blank holding force and drawbead directly affect the metal flow and formability of stamping. Then, by adjusting blank holding force and setting appropriate drawbeads, an optimized stamping process plan is obtained and is validated in experiments. Finally the phenomenon and displacement of distortion springback are predicted in the springback simulation, which is useful to further improve the quality of this kind of part.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 579-584
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.579
• Online since: July 2011
• Authors: Guang Kai Wang, Si Yuan Cheng, Su Yang Li, Xiang Wei Zhang
• Keywords: Box-Type Part, DYNAFORM, Numerical Simulation, Sheet Metal Forming, Springback

References

[1] Gantar.Gasper, Pepelnjak.Tomaz, Kuzman. Karl: Journal of Materials Processing Technology, Vol. 130-131(2002), p.54

[2] Kleiber.M, Rojek. J, Stocki. R: Computer Methods in Applied Mechanics and Engineering Vol. 191(2002), p.4511

DOI: 10.1016/s0045-7825(02)00394-8

[3] Lingjiang Cui: Automotive panel sheet metal forming technology (China Machine Press, Beijing 2003) in chinese

[4] Hanqing Yu, Jinde Chen: Principles of Metal Forming (China Machine Press, Beijing 2010). in chinese

[5] Yuhuang Jiang. Study on FEM numerical simulation analysis of sheet metal forming and springback. Nanjing University of Science and Technology (2007) in chinese

[6] Samuel.M: Journal of Materials Processing Technology Vol.122 (2002), p.94

[7] Wenliang Chen: Sheet metal forminug CAE analysis textbook (China Machine Press, Beijing 2005) in chinese

[8] S.K. Panthi, N. Ramakrishnan, K.K. Pathak and J.S. Chouhan: Journal of Materials Processing Technology, Vol. 186(2007), p.120

[9] ETA, Inc: eta/DYNAFORM User's Manual

[10] Zhihua Zhong, Guangyao Li: Computer application and simulation of sheet metal stamping process (Beijing Institute of Technology Press, Beijing 1998) in chinese

[11] Xin Nie. Study on problems related with auto panel springback. Doctoral dissertation, Hunan University (2008) in chinese
