Crack Failure Analysis of Q235B Welding with 304 Austenitic Stainless Steel of Tube and Shell Condenser

Abstract:

Tube and shell condenser is an important component of soybean softening equipment, and its structure is Q235B welding with 304 austenitic stainless steel pipes. During the using process of this product, it appears crack failure .In order to find the reason of crack failure, the welded joint was analyzed by SED, XRD, EDXRF and metallographic microscope in detail, and some improvement measures and solutions are put forward to avoid crack failure in this paper.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 975-978
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.975
• Online since: July 2011
• Authors: Xian Liang Zhang, Rong Fa Chen, Liang Gang Dai, Tao Liu, Yi Pan
• Keywords: Austenitic Stainless Steel, Structural Carbon Steel, Tube and Shell Condenser, Weld Joint

References

[1] Y.X. Zhang, Y.Wang, L.H. Zhang: Nei-jiang technology Vol.10(2009), p.91(in Chinese).

[2] W.F. Zhang: Pipe Vol.26(2003), p.53(in Chinese).

[3] L.S. Xiong, in: Welding engineering foundation, edtied by China Machine Press, China, BJ(2007), in press.

[4] Anwar Ul-Hamid, Hani M.Tawancy, Nureddin M.Abbas: Engineering Failure Analysis Vol.12(2005).

[5] J.Q. Tang, L.J. Zhang, J.M. Gong: Corrosion and Protection Vol.24(2003), p.180 (in Chinese) .

[6] Jong-Hyun Baek, Young-Pyo Kim, Woo-Sik Kim, Young-Tai Kho: International Journal of Pressure Vessels and Piping Vol.78(2001).

[7] L.Q. Han, G.B. Lin, Z.D. Wang, H.Zhang, F.Li, L.You: Rare Metal Materials and Engineering Vol.39(2010).

[8] Bulent Kurt: Journal of Materials Processing Technology Vol.190(2007).

[9] J.JI: Coal Mine Machinery Vol.29(2008), p.85 (in Chinese) .
