Interfacial Reaction of Alumina Ceramics to Mild Steel Braze Joint

Abstract:

Al₂O₃ is brazed with mild steel using 70Ag-27Cu-3Ti (wt.%) active filler alloy at 900°C for 5 min. The interfacial reaction products are analyzed with X-ray diffraction (XRD)．The interfacial phases are analyzed with EDAX. According to the experimental observations, the interfaces developed during brazing have been systematically characterized and the structure are separately Ti₃Cu₃O/Ti₃Al+ TiMn+TiFe₂ +Ag(s,s)+Cu(s,s)/TiC from alumina ceramics side to mild steel side.

• Periodical: Advanced Materials Research (Volumes 291-294)
• Pages: 954-957
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.291-294.954
• Online since: July 2011
• Authors: Zhuo Ran Li, Guang Dong Wu, Xiang Long Zhang, Jian Xin Fan, Ji Cai Feng
• Keywords: Ag-Cu-Ti Filler Alloy, Alumina Ceramics, Brazing, Interfacial Reaction

References

[1] K.Abhijit, M.Sudipta, K.Venkateswarlu, Characterization of interface of Al2O3–304 stainless steel braze joint, Materials Characterization. 58 (2007) 555-562.

DOI: 10.1016/j.matchar.2006.12.001

[2] P.T. Vianceo, J.J Stephens, P.F. Hlava, Titanium scavenging in Ag-Cu-Ti active braze joints, Weld. Res.82 (2003) 268-277.

[3] Y.C. Yoo, J.H. Kim, K.Park, Microstructural characterization of Al2O3/AISI 8650 steel joint brazed with Ag–Cu–Sn–Zr alloy,Mater. Lett. 42 (2000) 362-366.

DOI: 10.1016/s0167-577x(99)00212-8

[4] G.J. Qiao, C.G. Zhang, Z.H. Jin,Thermal cyclic test of alumina/kovar joint brazed by Ni–Ti active filler, Ceram Int. 29(2003) 7-11.

DOI: 10.1016/s0272-8842(02)00081-0

[5] A.V. Durov, B.D. Kostjuk, A.V. Shevchenko, Joining of zirconia to metal with Cu–Ga–Ti and Cu–Sn–Pb–Ti fillers, Mater. Sci. Eng. A. 290 (2000) 186-189.

DOI: 10.1016/s0921-5093(00)00916-3

[6] A.M. Kliauga, D.Travessa and M.Ferrante, Al2O3/Ti interlayer/AISI 304 diffusion bonded joint microstructural characterisation of the two interfaces, Mater. Charact. 46(2001) 65-74.

DOI: 10.1016/s1044-5803(00)00095-4

[7] D.Travessa, M.Ferrante and O.G. Den, Diffusion bonding of aluminium oxide to stainless steel using stress relief interlayers, Mater. Sci. Eng. A, 337(2002) 287-296.

DOI: 10.1016/s0921-5093(02)00046-1

[8] E.Siores and D.D. Rego, Microwave applications in materi-al joining, Mater. Process. Technol. 48(1995) 619-625.

[9] S.I. Matsuoka, Ultrasonic welding of ceramics/metals using inserts, Mater. Process. Technol. 75(1994) 259 -265.

[10] J.P. Rice, D.M. Paxton and K.S. Weil, Oxidation Behavior of a Commercial Gold-Based Braze Alloy for Ceramic-To-Metal Joining, Ceram. Eng. Sci. Proc. 23(2002) 809-816.

DOI: 10.1002/9780470294741.ch95
