Research on Parametric Design of Dedicated Computer

Abstract:

This paper is aimed at dedicated computer case. The solid models of dedicated computer were built by three-dimensional mechanical design software Pro/E; the parametric design of chassis components was carried out by the Pro/E secondary development tool Pro/Toolkit. A user application was created, including user-defined menus and user dialogs, so users can easily implement the models based on prototyping parts, and repeatedly modify them until satisfied, ultimately achieving the aim of improving design efficiency and saving design cost.

• Periodical: Advanced Materials Research (Volumes 295-297)
• Pages: 2474-2478
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.295-297.2474
• Online since: July 2011
• Authors: Shi Jie Li, Yan Rui Zhang, Bing Bing Shen, Hai Xia Bi
• Keywords: Parametric Design, Pro/E, Pro/Toolkit, Secondary Development

References

[1] Chunxia Xu, Jianhua Wang. Research on Secondary Development of CAD System Based on Pro/E (2004), pp.16-20

[2] Jichun Zhang: Practical Course of Secondary Development of Pro/E (2003), pp.1-56

[3] Hongqi Zhang: Technology and Practice of Developing Pro/E User's Menu (2003)

[4] Parametric Technology Corporation: Pro/Toolkit User's Guide [M]. USA: PTC, (2001)
