The Key Technology in Extrusion Tapping of Internal Thread

Abstract:

Internal thread processing is an indispensable procedure in manufacture, its processing efficiency and quality become more and more important in modern manufacturing, especially in aerospace and automotive industry. Compared with the traditional process of cut tapping of internal thread, the process of extrusion tapping of internal thread possesses the following advantages: without chip, higher precision, better surface quality, better continuity of metallic, greater efficient, greater strength, longer tool life. This paper firstly introduces the current research status of extrusion tapping of internal thread, elaborates the principle and characteristic of extrusion tapping, analyzes the matal plastic flow law and thread forming characteristic during tapping, then generalizes the influencing law of the key technology on thread forming quality, such as extrusion tap type, lead hole diameter, tapping speed and friction. Furthermore, puts forward some improvement approach to reduce tapping torque and enhance forming quality of internal thread.

• Periodical: Advanced Materials Research (Volumes 295-297)
• Pages: 2636-2641
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.295-297.2636
• Online since: July 2011
• Authors: Yong Yi Li, Sheng Dun Zhao
• Keywords: Extrusion Tapping, Internal Thread, Key Technology
