Finite Element Analysis of 35 Tons Steel Coil Overturning Machine

Abstract:

35 tons hydraulic overturning machine is the operating equipment that is mainly to make steel coil turn 90 ° and keep steel coil change from vertical position to level position or on the reverse. Because the dead weight value of overturning machine is extreme and the coil's weight which needs to turn is very heavy, the strength of equipment that is a very important design parameter plays a decisive role in the device security. By using the finite element analysis function of COSMOS Works to analyze the strength of overturning machine, which simplifies the design process, improves the design reliability and has value for the design of steel coil overturning machine.

• Periodical: Advanced Materials Research (Volumes 299-300)
• Pages: 921-924
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.299-300.921
• Online since: July 2011
• Authors: Feng Hui Wang, Anyuan Jiao
• Keywords: Finite Element Analysis (FEA), Overturning Machine, Strength Analysis

References

[1] Xu Zhiguan: Elastic mechanics , Higher Education Press, Beijing (2006).

[2] Benaroya H, Rehak M. Appl. Mech. Rev Vol. 41 -5 (1988), p.201.

[3] Meng Fanzhong: Tsinghua University Press, Beijing(1985).

[4] Kong. L , Fuh. J. Y. H , Liu. X. L et al. Journal of Materials Processing Technology Vol. 139-13 (2003), p.81.

[5] Solidworks Corp. Machine Design Vol. 75-53 (2003), p.96.

[6] Leistung. Technica-Rupperswil Vol. 58-1 (2009), p.59.

[7] Baofa Zhang. CAD Magazine Vol. 20-2(2009), p.63.
