A Vernier Delay Line for Time Interval Measurement

Abstract:

This paper presents a Vernier Delay Line (VDL) for time interval measurement. A dedicated multiplexer is inserted into each stage of the proposed VDL. As a result, the D-flip-flops in each stage can be served as a large delay cell as well as a traditional arbiter. Moreover, the proposed interface circuit can save time residue out for further fine granularity measurement. Experimental results show that the proposed VDL achieves a 30ns measurement range with 6600 transistors.

• Periodical: Advanced Materials Research (Volumes 301-303)
• Pages: 995-1000
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.301-303.995
• Online since: July 2011
• Authors: Xin Gang Wang, Fei Wang, Hai Gang Yang
• Keywords: Large Measurement Range, Time Interval Measurement, Vernier Delay Line (VDL)
