Material Removal Mechanisms of Electric Discharge Milling Conductive Ceramic

Abstract:

Material removal mechanisms of Al2O3-based conductive ceramics machined by electric discharge milling in deionized water are investigated. The main components of conductive ceramic samples are Al2O3 (80%), TiC (11%) and WC (9%). The material removal mechanisms by low electric discharge energy are mainly spalling and melting. The material removal mechanisms by high electric discharge energy are mainly melting, evaporation and spalling. With high discharge energy and insufficient cooling conditions, chemical reactions will happen, where TiC and WC are oxidized to dielectric TiO2 and WO3, which will slow down the electric discharge milling processand finally make it stopped.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 1746-1750
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.1746
• Online since: August 2011
• Authors: Wei Jie Chang, Jian Hua Zhang, Tao Zhu, Tao Wang
• Keywords: Conductive Ceramic, Deionized Water, Electric Discharge Milling, Material Removal Mechanisms

References

[1] B. Lauwers, J.-P. Kruth, K. Brans, Development of Technology and Strategies for the Machining of Ceramic Components by Sinking and Milling EDM, Annals of the CIRP 56(2007) 225-228

DOI: 10.1016/j.cirp.2007.05.053

[2] König, W., Dauw, D.F., Levy, G., Panten, U., EDM-Future Steps towards the Machining of Ceramics, Annals of the CIRP 37(2) (1998) 623-631

DOI: 10.1016/s0007-8506(07)60759-8

[3] Yonghong Liu, Renjie Ji, Qingyun Li, et al., Electric discharge milling of silicon carbide ceramic with high electrical resistivity, International Journal of Machine Tools & Manufacture 48(2008) 1504-1508

DOI: 10.1016/j.ijmachtools.2008.03.012

[4] K. Liu, D. Reynaerts, B. Lauwers, Influence of the pulse shape on the EDM performance of Si3N4-TiN ceramic composite. CIRP Annals – Manufacturing Technology 58(2009) 217-220

DOI: 10.1016/j.cirp.2009.03.002

[5] Z.X. Jia, Z.Y. Wang, Z.J. Guo, Study on the surface quality of Si3N4 ceramics machined by wire EDM, Metallurgical Equipment 25 (2005) 1–7

[6] J. Kozak, K.P. Rajurkar, N. Chandarana, Machining of low electrical conductive materials by wire electrical discharge machining (WEDM), Journal of Materials Processing Technology 149 (2004) 266–271

DOI: 10.1016/j.jmatprotec.2003.11.055

[7] B. lauwers, J.P. Kruth, W. Liu, et al., Investigation of material removal mechanisms in EDM of composite ceramic materials, Journal of Materials Processing Technology 149(2004) 347-352

DOI: 10.1016/j.jmatprotec.2004.02.013
