Analysis to Dynamic Characteristics Influence on Bearing-Load Sensor to the Rotor System

Abstract:

For a multi-bearing rotor test bed, using the load sensor designed specially measured directly the bearing load value. In order to analyze the dynamic influence of the load sensor on the rotor system, the dynamic equation of the rotor system with the load sensor established to do the qualitative analysis. On the other hand, quantitative analyzing the two structures that the sensor is installed and is not by finite element software ANSYS, and obtained the impact value. The results show that the load sensor reduced the critical speed of the rotor system, but the effect is not, can be appropriately adjusted work speed according to the results of the analysis.

• Periodical: Advanced Materials Research (Volumes 308-310)
• Pages: 2551-2554
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.308-310.2551
• Online since: August 2011
• Authors: Xin Yu Pang, Zhao Jian Yang
• Keywords: Bearing-Load, Dynamic Influence, Finite Element Analysis (FEA), Sensor

References

[1] L.X. Xu: Dynamic Design of High-Speed Rotary Shaft (National Defence Industry Press, China 1994). (In Chinese)

[2] Z.J. Yang, Y.B. Xie: China Mechanical Engineering, Vol.4(1997)No.8,p.89. (In Chinese)

[3] X.Y. Pang, Z.J. Yang, H.Y. Lu, Q.L. Liang & H.E. Sun: Seventh International Symposium on Instrumentation and Control Technology(Beijing,China,November 10-12,2008).Vol.1,p.2007.

[4] X.Y. Pang, Z.J. Yang, Q.L. Liang & H.E. Sun: Journal of taiyuan university of technology, Vol.40(2009) No.5,p.461.(In Chinese)

[5] L.M. Li: The Practical Course of ANSYS Finite Elemen Analysis (Tsinghua University Press, China 2005). (In Chinese)
