Effects of Different Solder Alloys on Reliability of 3D PLUS Solder Joint

Abstract:

Thermal cycling was applied to assess the effect of tin-lead solder 63Sn37Pb and lead-free solder 95.5Sn3.8Ag0.7Cu on the reliability of 3D PLUS solder joints. Nonlinear finite element method and viscoplastic Anand model were used to evaluate the stress and strain distribution and dangerous position of solders under the thermal cycling condition. The law of solder joints stress and plastic strain were finally obtained and showed significant cyclical changes. The stress and strain emerged the trend of accumulated enhancement with the process of time, then ultimately stabilized. Comparing two curves of equivalent stress and plastic strain obtained from lead-free and tin-lead solder, it was found that the reliability of 95.5Sn3.8Ag0.7Cu was better than that of 63Sn37Pb.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 1038-1042
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.1038
• Online since: August 2011
• Authors: Nuo Bao, Chun Jie Wang, Lin Zhu, Shun Guang Song
• Keywords: Anand Visco Plasticity Model, Equivalent Plastic Strain, Equivalent Stress, Finite Element, Solder Paste

References

[1] J. Lau, W. Dauksher: Reliability of an 1657CCGA package with 95.5Sn3.9Ag0.6Cu lead-free solder paste on PCBs, Journal of Electronic Packaging, Vol. 127 (2005) No.2, p.96.

DOI: 10.1115/1.1846069

[2] D. Herkommer, J. Punch, M. Reid: A reliability model for SAC solder covering isothermal mechanical cycling and thermal cycling conditions, Microelectronics Reliability, Vol. 50 (2010), No.1,p.116.

DOI: 10.1016/j.microrel.2009.08.008

[3] D.K. Shangguan: Lead-Free Solder Interconnect Reliability (Publishing House of Electronics Industry, China 2008)

[4] L. Anand: Constitutive Equations for the Rate-dependent Deformation of Metals at Elevated Temperature, Journal of Engineering Materials and Technology, Vol. 104 (1982) No.1, p.12.

DOI: 10.1115/1.3225028

[5] G.Z. Wang, Z.N. Cheng, K.Becker et al: Applying Anand Model to Represent the Viscoplastic Deformation Behavior of Solder Alloys, Journal of Electronic Packaging, Vol. 123 (2001) No.9, p.247.

DOI: 10.1115/1.1371781

[6] Z.N. Cheng, G.Z. Wang, L.Chen et al: Viscoplastic Anand model for solder alloys and its application, Soldering&Surface Mount Technology, Vol. 12 (2000) No.2, p.31.

DOI: 10.1108/09540910010331428

[7] T.H. Wang, Y.S. Lai: Submodeling Analysis for Path-Dependent Thermomechanical Problems, Journal of Electronic Packaging, Vol.127 (2005) No.7, p.135.

DOI: 10.1115/1.1869513

[8] Z. Li, M.R. Zhao, M. You et al: Proc. IEEE International Conference on Energy and Environment Technology (Guilin, Guangxi ,China, October 16-18, 2009). Vol. 1, p.214.

[9] B. Rodgers, J. Punch, C. Ryan et al: Proc. ASME International Mechanical Engineering Congress and Exposition (Anaheim, California, USA, November 13-19, 2004). Vol. 4, p.153.
