An Optimum-Curved Die-Profile for Investment Casting of Turbo Blades

Abstract:

In order to avoid tremendous modifications of the die cavity for investment casting of turbo blades, this paper proposed an inverse iterative compensation method that adjusts certain geometric parameters to establish the die-profile. The parameterized modeling is achieved by identifying geometric parameters describing the mean camber line; the optimum-curve die-profile can be obtained based on the inverse iteration algorithm. As a result, the dimension precision of turbo blades can be guaranteed. The applicability of this method is validated using numerical simulation data.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 630-633
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.630
• Online since: August 2011
• Authors: Yi Wei Dong, Ding Hua Zhang, Kun Bu, Yang Qing Dou
• Keywords: Die-Profile, Geometric Parameter, Inverse Iteration Algorithm, Investment Casting

References

[1] D. Zhang, R. Jiang, J. Li, W. Wang, K. Bu, Int J Adv Manuf Technol 48, 839 (2010).

[2] S.C. Modukuru, N. Ramakrishnan, J Mater Process Tech 58(2-3), 223 (1996).

[3] Sabau A. Metallurgical and Materials Transactions B, 2006, 37(1): 131.

[4] Chen L , Lin G C I. Robotics and Computer-Integrated Manufacturing, 2000, 16(2-3): 161.

[5] L N. Zhang, D. Zhang, Y. Liu, (Xi'an, China, 2006), vol. 532-533, p.777–780.

[6] T. Korakianitis, T. Sadoi, J Eng Gas Turb Powe 127(3), 525 (2005).

[7] N. Kumar, C. Besant, M. Ristic, Int J Adv Manuf Technol 3, 3 (1988).
