Research on a Scheme of Real-Time Measuring of Lubrication Oil Quantity in an Aero-Engine Tank

Abstract:

The composition and principles of the digital measuring system was investigated on the basis of digital oil measuring method. Fly attitude-oil quality - measuring height data tables were generated by using UG software calculation of oil quantity characteristics. Then the oil surface angle under different fly attitude and overload was calculated through coordinate transformation method. Finally the amount of oil was calculated by three-dimensional liner interpolation method. Meanwhile, the free surface movement of lubricating oil tank under different overload was simulated through VOF numerical model. The results showed that using UG software to build model and generate fly attitude-oil quantity-measuring height data tables is accurate and useful. The VOF model method is a complement to digital measurement, which can track the phase interface of continuum, analyze the movement of oil qualitatively and calculate the dead volume of digital method.

• Periodical: Advanced Materials Research (Volumes 317-319)
• Pages: 2079-2084
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.317-319.2079
• Online since: August 2011
• Authors: Rang Shu Xu, Xiao Wen Chen, Jian Ming Yang, Zhi Wei Dong, Min Li Bai
• Keywords: Digital Measurement of Oil, Lubrication Oil Tank, Three-Dimensional Linear Interpolation, Volume of Fluid (VOF) Model

References

[1] Chief Editing Organization of《Aeroengine Design handbook》.The twelfth volume of aeroengine design Handbook: transmiss-ion and lubrication system [M]. Beijing: Aviation Industry Pr-ess, 2002. In Chinese

[2] Yang Pengtao, Niu Liang, Jiang Junchang. Research of fuel quantity gauging syncopation step-size choosing based on aircraft fuel tank model shape feature [J]. Acta Aeronautica et Astronautica Sinica, 2008, 29(3) 657 – 663. In Chinese

[3] Osgar John Ohanian .Mass Properties Calculation and Fuel Analysis in the Conceptual Design of Uninhabited Air Vehicles[D].Virginia Polytechnic Institute and State University,2003.

[4] Junchang Jiang. Aircraft fuel management system for digital [D]. Northwestern Polytechnical University,2002. In Chinese

[5] Zhong Shisheng, Lei Da. Aeroengine Lubrication Oil Consumption Rate Prediction Based on the Process Support Vector Machin [J]. Lubrication engineering, 2009，34（10）：6-9. In Chinese

[6] Fukuang Duan. Computer-aided analysis of aircraft fuel [D]. Nanjing University of Aeronautics and Astronautics, 2004. In Chinese

[7] Jang Dongfang, Chen Qiu, Chen Ming. A dynamic neural network fuel measurement method for fuel tank on aircraft [J]. Aeronautical Computing Technique, 2000, 30(2):12-15. In Chinese

[8] Wang Xiangyang, Zhuang Damin, Liu Jianmin. The research of aircraft fuel quantity gauging method [J]. Aircraft Design, 2004 (1):47-51. In Chinese

[9] Zhen ping Fang, Yangchuan Chen, Shuguang Zhang. Flight Dynamics of Aviation Aircraft [M]. Beijing University of Aeronautics and Astronautics Press, 2010.2. In Chinese

[10] Meng Wenshun, Yang Yunjing. Principle and application of capacity sensor [J]. Modern Electronic Technique, 2003, (7):78-81. In Chinese

[11] Guan Li, Chen Xinglu. A method for the date process in fuel quantity gauging on aircraft by multidimensional table look-up technique [J]. Test and Technique, 1997, 16 (1): 41-43. In Chinese
