Research on the Simulation of Airflow Field in Cyclone Separator Based on ANSYS

Abstract:

In this paper, we use ANSYS to simulate the cyclone separator, analysis the velocity of the internal airflow field, pressure distribution and temperature distribution. The result shows that the mainstream of a cyclone separator is double rotating flow, and in the outer downstream areas, with the increase of the radius, the airflow rate decreases accordingly; In the inside upstream region, flow velocity at the center is larger, while flow around is smaller relatively; Besides, the total pressure in the inport section of the cyclone is highest, and the pressure inside of the exhaust pipe is lowest. The mainstream of the airflow field is double-rotating in the cyclone flow; The distribution of airflow temperature is related to the flow field distribution.

• Periodical: Advanced Materials Research (Volumes 317-319)
• Pages: 2069-2072
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.317-319.2069
• Online since: August 2011
• Authors: Zhen Wei Zhang, Yong Song, Wei Wei Cao
• Keywords: ANSYS, Cyclone Separator, Flow Field, Numerical Simulation

References

[1] Ming-Xian, Wu Xiaolin. cyclone separation technology Research and Development [J], Beijing:four decades of oil higher, 1995, 10 (2): 49-51.

[2] Tao, Yang Fengpeng. proficient in ANSYS [M], Beijing:Tsinghua University Press, 2002, 213-230.

[3] Kenny Wong, cyclone within the three-dimensional numerical simulation of flow field and performance calculations [D], Beijing: Petroleum University, a master's degree thesis, 2000,5.

[4] Wang Haigang, Liu Shi. different turbulence models in thecyclone numerical simulation and comparison [J], Thermal Power Engineering, 2003,18 (4): 337-342.
