Parameter Design and Application of Hydraulic Support with Hanging Chain and Splicing Beam in Shallow Seams

Abstract:

In view of actual situation of serious resources waste and less than 30% of face recovery ratio to shallow seams with existing features of harder roof at the process of room and pillar mining in northern Shaanxi province in China, reasonable support strength has been studied in both cases of normal mining and force caving for improved longwall mechanized mining face, and obtained reasonable working support resistance at the condition of force caving which was better than normal mining. Based on this condition, Shandong Xin Mei machinery Co, Ltd. has developed hydraulic support with hanging chain and splicing beam which was suitable to existing features of shallow seams. The support had advantages with flexible connection between supports to ensure that all pillars reached rated setting load, sub-size top beam to resolve "protection" and "cutting" dilemma for the roof, adjusting and locking support, etc. The company also has given concrete support parameters. By the field industrial test verification, the developed new support fully adapted strata behavior at the process of force caving with existing features of shallow depth and harder roof. The research has provided a useful reference for other coal mines with similar geological features.

• Periodical: Advanced Materials Research (Volumes 317-319)
• Pages: 2244-2248
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.317-319.2244
• Online since: August 2011
• Authors: Xiao Ping Shao, Yu Cheng Xia, Ping Wu Shi
• Keywords: Force Caving, Hydraulic Support with Hanging Chain and Splicing Beam, Shallow Seam, Support Strength

References

[1] Da Men, Jiachen Wang and Jingxue Wang. Journal of China Coal Society, Vol. 32-6 (2007), pp.577-580, in Chinese.

[2] Caiping Liu, Jingan Wang and Zhiying Hou. Mining Research and Development. Vol. 28-1 (2008),pp.8-12, in Chinese..

[3] Fengqi Bao. Coal mining Technology, Vol.13-6 (2008),pp.17-19, in Chinese.

[4] Yu Chen. Coal Mine Machinery, Vol.29-12 (2008),pp.47-49, in Chinese.

[5] Dejun Song. Journal of Taiyuan University of Technology. Vol.37-5 (2006), pp.568-571, in Chinese.

[6] Xiaoping Shao, Pingwu Shi. Coal Technology, Vol.29-6 (2010), pp.97-99, in Chinese.
