Research on the On-Line Model for Energy Efficiency Diagnosis of Thermal Power Pulverized Coal Boiler

Abstract:

This paper presents one on-line model for energy efficiency calculation and analysis. The computation model of combustion rate and other related physical and chemical equations were introduced to the heat balance computing model of boiler. It established one on-line model of thermal process, which can provide the functional relationship completely in real-time measurable variables to the calculation of energy efficiency. And on that basis, the theory on deviation analysis was introduced to establish the model for energy efficiency quantitative analysis to calculate the single-factor distributed consuming difference. The situation of the CG-220/9.81-M boiler’s energy efficiency was calculated and analyzed with the diagnosis model. The calculation errors of thermodynamic parameters related and the errors between the lumped energy efficiency deviation and the sum of single-factor distributed efficiency deviation were both small. The model is reasonably accurate. The on-line model for energy efficiency diagnosis of thermal power pulverized coal boiler was established.

• Periodical: Advanced Materials Research (Volume 320)
• Pages: 542-547
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.320.542
• Online since: August 2011
• Authors: Yang He, Su Fen Li
• Keywords: Deviation Analysis, Energy Efficiency Diagnosis, On-Line Model of Thermal Process, Thermal Power Pulverized Coal Boiler

References

[1] Janusz Gola: SPIE- International Society for Optical Engineering, Gliwice, Poland, 2000.

[2] PAN Wei-guo: Proceedings of the Csee, 2004, Vol. 24(10), pp.193-195.

[3] QIN Shouxuan: Proceedings of the Csee, 2010, Vol. 30(32), pp.30-34.

[4] FENG Junkai, SHENG Yongting, in: Boiler principle and calculation (Beijing Science press 2003).

[5] GAO Daming in: Study of Optimization Control of Combustion System in Power Plant Boiler ( North China Electric Power University, 2005).

[6] Haijun Li in: 2010 International Conference on Advances in Energy Engineering, Beijing, China, 2010.

[7] Liu Fuguo: submitted to Thermal Power Generation, 2003(1), pp.15-19.

[8] M.A. Field, in: Combustion of Pulverised Coal. (Beijing Hydraulic power press, 1989).
