Design of Accelerator in Wind Power Generator with Creative Mechanical Design Methodology

Abstract:

With today’s rapid development of science and technology, mechanical design calls for more advanced methodologies. The Creative Mechanical Design Methodology established by Yan [1] is one of the most effective ways to form new mechanisms according to existing ones based on certain requirements. However, few research of this method applied on transmission mechanism exists, especially gear trains with large rated power and transmission ratio. This paper introduces how the Creative Mechanical Design Methodology is applied in the design of the accelerator (gear box) with an output power of 1.25 MW in wind power generator. In the process, feasible schemes are obtained following the steps of Creative Mechanical Designing, and an evaluation based on practical manufacturing, assembly and application situations is conducted to obtain the best mechanism among all these schemes.

• Periodical: Advanced Materials Research (Volume 323)
• Pages: 94-98
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.323.94
• Online since: August 2011
• Authors: Bo Zhang, Ji Ning Qiu, Hui Min Dong
• Keywords: Creative Design, Evaluation, Gear Train, Wind Generator

References

[1] Hongsen Yan, Creative Design of Mechanical Devices, China Machine Press (2002)

[2] Site Witness sector, Wind Energy World Magazine, Nov. (2009)

[3] Delun Wang, Yuan Gao, Theory of Machines and Mechanisms (Internal teaching material of Dalian University of technology), (2010)

[4] Robert L. Norton, Design of Machinery--An Introduction to the Synthesis and Analysis of Mechanisms and Machines, The McGraw-Hill Companies, Inc. (2007)

[5] Yongsheng Shen, Theory of Machines and Mechanisms (2007)

[6] Committee of Mechanical Design, Section 17, Chinese Mechanical Design Handbook, China Machine Press (2007)
