Microstructure and Microwave Dielectric Properties of BaTi₄O₉ Ceramics Derived from a Sol-Gel Precursor

Abstract:

In the present work, the microstructure and microwave dielectric properties of BaTi₄O₉ ceramics derived from a sol-gel precursor were presented. Density measuring results demonstrated that the largest densities of ceramic sample about 96.7% could be reached by virtue of a cool iso-static press and a sintering process at at 1300 °C for 6 hours. The dielectric constant (ε_r), quality factor (Q×f) and the temperature coefficients (τ_f) of the BaTi₄O₉ ceramic samples were 36.65, 28000 GHz, +20.2 ppm/°C, respectively. XRD, SEM and XPS were used to characterize the microstructure of the ceramics samples. Substantial Ti³⁺ was proposed to be the cause of dielectric loss.

You might also be interested in these eBooks

Advanced Materials for Applied Science and Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 326)

Pages:

127-130

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.326.127

Citation:

Cite this paper

Online since:

September 2011

Authors:

Xian Li Huang, Fu Ping Wang, Ying Song

Keywords:

Lattice Vibration, Microstructure, Microwave Dielectric Ceramics, Titanate

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] D.J. Masse, R.A. Pucel, A new low-loss high-k temperature- compensated dielectric for microwave applications. Readey Proc. IEEE, l. 59 (1971) 1628-1671.

DOI: 10.1109/proc.1971.8508

Google Scholar

[2] T. Negas, BaTi4O9/Ba2Ti9O20-based ceramics resurrected for modern microwave applications J. Am. Ceram. Soc. Bull. 72(1993)80-89.

Google Scholar

[3] G. Wolfram, H E. Gobel. Existence range, structural and dielectric properties of ZrxTi ySn zO4 ceramics (x+ y+ z= 2). Mater Res Bull. 16(1981)1455-1153.

Google Scholar

[4] M. Furura and A. Ochi, Microwave Dielectric Properties for Ba (Mg1/3Ta 2/3)O3-A (Mg1/2W2/3) O3 (A= Ba, Sr, and Ca) ceramics. Jpn. J. Appl. Phys. Part 1, 33 (1994) 5482-5486.

DOI: 10.1063/1.369232

Google Scholar

[5] J. Pezelt, R. Zurmuhlen, A. Bell, Dielectric spectroscopy of some Ba(B1/2B1/2)O3 complex Perovskite in the 1011-1014 Hz gange. Ferroelectrics, 133 (1992) 205-210.

Google Scholar

[6] J. J. Ritter, R. S. Roth, and J. E. Blendell, Alkoxide Precursor Synthesis and Characterization of Phases in the Barium-Titanium Oxide System. J. Am. Ceram. Soc. 69(1986) 155-162.

DOI: 10.1111/j.1151-2916.1986.tb04721.x

Google Scholar

[7] M H. Weng, T. J. Liang, C. L. Huang. Lowing Sintering Temperature Microwave Properties of BaTi4O9 Ceramics Prepared by the Polymeric Precursor Method. J. Euro. Ceram. Soc. 22(2002)1693-1698.

DOI: 10.1016/s0955-2219(01)00472-1

Google Scholar

[8] W. Fuping, L. Wenxu, S. Ying, Fabrication of single-phase BaTi4O9 nanocrystalline powder by sol-gel process . J. Sol-Gel Sci. Tech., 23 (2002) 39-41.

Google Scholar

[9] F. W. Harrison,. The Unit Cell and Space Group of Barium Tetratitanate BaO-4TiO2. Acta. Cryst., 9 (1956) 198-203.

DOI: 10.1107/s0365110x56000504

Google Scholar

[10] S. Ying., W. Fuping, J. Zhaohua,. Effect of BaTi4O9 fibers on Dielectric Properties of 0. 64BaTi4O9+0. 36BaPr2Ti4O12 Composites. Ceram. Inter., 28 (2002) 685-688.

Google Scholar
