The on-Line Detection of Drafting Force of Back Zone on Cotton Spinning Frame

Abstract:

In this paper, the way and equipment that detects the drafting force of back zone on cotton spinning frame is promoted and designed, on the base of the analysis of draft theory, detected equipment and way of drafting force in existence. Using this way, the drafting force of back zone on spinning frame can be detected on-line effectively. By mechanical analysis way, in the course of drafting the mathematical models of drafting force in back zone and force impressing on sensor are educed; the drafting force is detected on cotton spinning frame utilizing detected equipment of drafting force designed by ourselves. Results indicate: this detected equipment can reflect the size and wave circs of drafting force in back zone, provide a new way of on-line detection of drafting force in back zone on cotton spinning frame and choice drafting process parameters in reason.

• Periodical: Advanced Materials Research (Volumes 332-334)
• Pages: 520-525
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.332-334.520
• Online since: September 2011
• Authors: Jia Zhi Ren, Qing Guo Feng, Guo Xin Jia, Yi Feng Zhang
• Keywords: Draft Multiple of Back Zone, Drafting Force, Online Detection, Spinning Frame

References

[1] (Former Soviet) Kuofnier С.С.etc.n. The Research of Drafting Force [M]. Textile Industry Press.(1959)

[2] Martindale J.G. JTI. Vol.38(1947), p.151

[3] H. R. Plonsker and S.Backer. TRJ. Vol.37(1967),p.673

[4] G. A. Foster. JTI. Vol.36(1945),p.229

[5] G. A. Foster. JTI. Vol. 42(1951), P.335

[6] G. A. R. Foster. JTI. Vol. 41(1950),p.357

[7] D. R. Cox and J. JTI. Vol. 41(1950), p.376

[8] (Japan) Xiaochuanzhaoruo. Ring Spinning Frame [M]. Wu Zhou Press. (1978)

[9] Borong Zhu. Autoleveller[M]. Textile Industry Press. 1986:250-252

[10] J. S. Olson. TRJ. Vol. 44(1974),pp.852-855

[11] Guangyi Rong, Hongqi Tai.Textile Technology. Vol.3 (1963),p.1

[12] Guotao Liu. Journal of Wuxi University of Light Indusrty. Vol. 13 (1994), p.251

[13] Guotao Liu. Journal of Wuxi University of Light Indusrty. Vol. 13 (1994), p.358

[14] Invention patent: on-line Detection Equipment and Way of Drafting Force of Drawing Frame

[15] Invention patent: The Drawing Equipment Which Can on-line Detect Drafting Force of Staple

[16] J. S. Olson. TRJ. Vol. 44(1974),p.852

[17] Jiazhi Ren. Textile Technology &Machinery（I）[M]. China Textile &Apparel Press.2004:156-226

[18] Guotao Liu. Morden Cotton Spinning Technological Base. [M] Textile Industry Press, 1999. pp.128-137.

[19] JOHN S. GRAHAM , CHARLES K. BRAGG. TRJ. Vol.42(1972),p.175
