Finite-Element Analysis of the Double Lateral Compression of Clad Tube into a Symmetric Square-Tube

Abstract:

The squaring process to shape a circular tube into a symmetric square clad tube is examined by a three-dimensional incremental elastic-plastic finite-element method based on an updated Lagrangian formulation. The effects of various parameters, such as geometric ratio R/t, strain hardening exponent n, friction coefficient μ, and the length of tube L, on the occurrence of collapse in the squaring process are discussed and interpreted in a theoretical manner. The findings show that geometric ratio is the major factor in the process of squaring circular tubes. When R/t=25, serious collapse is likely to appear. Aiming at circular tubes with geometric ratio R/t=25, this study proposes six analysis configurations for clad tubes to discuss the possibility of clad tubes avoiding collapse. The findings showed that clad tubes could effectively reduce the collapse ratio.

• Periodical: Advanced Materials Research (Volume 337)
• Pages: 332-335
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.337.332
• Online since: September 2011
• Authors: Tsung Chia Chen, Jiun Ming Ye
• Keywords: Clad Tube, Collapse, Elastic-Plastic, Square-Tube, Squaring

References

[1] D.K. Leu: J. Mater. Process. Technol. Vol. 178 (2006), p.287

[2] D.K. Leu, and J.Y. Wu: Int. J. Adv. Manuf. Technol. Vol. 25 (2005), p.691

[3] R.M. McMeeking, and J.R. Rice: Int. J. Solids Struct. Vol. 11 (1975), p.601

[4] H.L. Cao, and C. Teodosiu, in: Proc. of the Comput. Plast. - fundam. and appl., Barcelona, Spain (1989), p.959

[5] J.T. Oden, and E.B. Pries: Trans. ASME J. Appl. Mech. Vol. 50(1) (1983), p.67

[6] M.J. Saran, and R.H. Wagoner: Trans. ASME J. Appl. Mech. Vol. 58(2) (1991), p.499
