Ultrasound Wireless System for Sensor Data Transmission of Ultra-Thickness Plank

Abstract:

In this paper, Ultrasound Wireless System is introduced for wireless communication between the sides of ultra-thickness plank without breach of the structure. This system could be applied in the plank of the difference material of metal or non-metal and in environment in which high seal condition is required in uttermost, for instance ultra-pressure, radiation and virulent test. In this wireless system, the ultrasonic telemetry using single pulse for driving and receiving PZT has been designed and built to demonstrate the ability of the ultrasonic telemetry. This paper describes the designed transmitting circuit and receiving circuit and the results of a pilot set up. The driving characteristics and frequency response of PZT was analyzed and tested. It is very important that the transmitting circuit and receiving circuit were designed according to the frequency characteristics of the PZT and coupling, that is, the width of pulse and frequency of signal for the driving PZT must be properly chosen. It has been shown that communication of sensor signals can be made at two sides of steel enclosed container using PZT as ultrasonic transmitters and receivers.

• Periodical: Advanced Materials Research (Volume 346)
• Pages: 882-888
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.346.882
• Online since: September 2011
• Authors: Yong Jian Feng, Shao Jie Wang
• Keywords: PZT, Single Pulse, Ultrasound (US), Wireless System

References

[1] . Hwang, etal., bAHandheldImagingArraySystemQ. InvitedPaper, SPIEMedicalImagingSymposium, in: ProceedingofSPIE, SanDiego, vol. 3664, 2009(February), p.194–201.

[2] Hwang, etal., Handheldultrasoundimagingdeviceforbattlefieldtrauma, InvitedPaper, 1998IEEESonicandUltrasonicSymposiumProceeding, Sendai, Japan, 1998(October), p.1663–1667.

[3] Blevins RD, Tilden BW, Martens DH. Vortex-induced vibration and damping of thermowells. Flow-Induced Vibration. ASME 1996; PVP-328: 465– 484.

DOI: 10.1006/jfls.1997.0150

[4] Dunmire B, Beach KW, Labs KH, et al. Cross beam vector Doppler ultrasound for angle-independent velocity measurements. Ultrasound Med Biol 2000; 26: 1213–1235.

DOI: 10.1016/s0301-5629(00)00287-8

[5] A. NOISER, R.K. KAPANIA and J.N. REDDY 2003 American Institute of Aeronautics and Astronaut114ics Journal 8, 2335-2346. Free vibration analysis of laminated plates using a layer wise theory.

[6] J.R. FRIEND, D.S. STUTTS 2007 Journal of Sound and Vibration 204(3), 421-437. The dynamics of an annular piezoelectric motor stator.

DOI: 10.1006/jsvi.1996.0944
